Samsung mini DVM Series User Manual

Disassembly and Reassembly
Samsung Electronics4-37
No Parts Procedure Remark
3 Ass’y Control In
1) After disassembling indicating screw,
detach the Cover-Control.
2) Detach the Motor-Fan in and Sensor
Connector connected to PCB.
3) Hold the Ass'y Control In by hand to
lift up a little and then release the status
of hanging on the hanging slot.
