7.1 Printer overview
These are the main components of your machine:
7.1.1 Front view
1 ADF (Automatic Document Feeder)1
2 document width guides
3 document input tray
4 document output tray
5 control panel
6 multi-purpose tray
7 front cover
8 release lever
9 scanner lid
10 tray 1
11 optional tray 2
12 multi-purpose tray extension
13 multi-purpose tray paper width guides
14 scanner glass
15 toner cartridge
16 drum cartridge
1. SCX-6122FN has the ADF function, while SCX-6322DN uses the duplex ADF function.
