Samsung SCX-6322DN Service Manual

2
2
Specification of Product
Samsung Electronics
Service Manual
2-1
2. Specification of Product
2.1 Product Overview
Concept
- High network Feature , A4 Copier based MFP
Target User
- General Office
- Government, Education, Medical Vertical Market
- Duty Cycle : 20K Pages
Series Models
- SCX-6122FN(4-in-1, ADF NW)
- SCX-6322DN(4-in-1, DADF, NW)
Key Sales Point
- Duplex Capability
- Network Standard
- Scan-to-Email
- Large Volume Capability
2.2 Product Specification
2.2.1 Product General Specification
SCX-6122FN SCX-6322DN
Standar d
Local connection: Copier, Printer, Scan, Fax,
ADF
As Network connected: Network Print, Scan to
Client/SMB/FTP/Emai l
Local connection: Copier, Printer, Scan, Fax ,
DADF
As Network connected: Network Print, Scan to
Client/SMB/FTP/Emai l
Option 2nd Cassette, Desk 2nd Cassette, Desk
without Tray 2 560 X 430 X 455 mm 560 X 430 X 495 mm
with Tray2 560 X 430 X 595 mm 560 X 430 X 635 mm
22.55Kg 22.65Kg
20*2 Char 20*2 Char
Standar d
USB 2.0, IEEE 1284 Parallel Port, Ethernet 10/100 base Tx USB 2.0, IEEE 1284 Parallel Port, Ethernet 10/100 base Tx
Option N/A N/A
Avg operation 450W 450W
Sleep Mode 28W 28W
Standby Mode 100W 100W
Operatin g W arming up : 48dB, Printing/Coping/Scan : 60dBA Warming up : 48dB, Printing/Coping/Scan : 60dBA
Standby Less than 40dBA Less than 40dBA
Warm Up Time
from sleep mode
Less than 30 sec. Less than 30 sec.
Monthly Duty Cycle 20,000pages 20,000pages
Machine Life
5Years or 300,000 Pages, which comes first
5Years or 300,000 Pages, which comes first
ADF Feed Roller
50,000pages
50,000pages
Paper Feeding Roller
100,000pages
100,000pages
Transfer Roller
100,000pages
100,000pages
Fuser Unit
100,000pages
100,000pages
64MB
I/O Interfac e
Noise
Device Memory
Machine Life
Power
Consumptio n
Items
Major
Functions
Dimensio n
(WxDxH )
Net Weight (with CRU)
LC
D
64MB
