Samsung SCX-6322DN Service Manual

Exploded View & Parts List
Samsung Electronics
Service Manual
8-1
8
8
8. Exploded Views and Parts List
8.1 Main 8-2
8.2 Housing Scanner
8-3
8.3 OPE Cover
8-4
8.4 Platen Cover Ass'y
8-5
8.5 ADF Ass'y
8-6
8.6 DADF Ass'y
8-7
8.7 DADF Platen Cover Ass'y
8-8
8.8 DADF SUB Ass'y
8-9
8.9 Side Cover Ass'y
8-10
8.10 Cassette Ass'y
8-11
8.11 Exit Ass'y
8-12
8.12 Feeder Ass'y
8-13
8.13 MP Ass'y
8-14
8.14 Base Frame
8-15
8.15 Pick-up Ass'y
8-16
8.16 Drive Ass'y
8-17
8.17 Main Frame Ass'y
8-18
8.18 FuserAss'y
8-19
8.19 SCF Unit(Option Cassette)
8-20
Contents
