Drawer# Description SEC_Code QT'y Service
Service(SA:service available, SNA:service not avaialble)
8.7-10 MEA UNIT-HINGE(MCK2) JC97-01839A 2 SA
8.7-11 PLATE-P-DUMMY PLATEN JC61-00819A 1 SA
8.7-12 SPRING ETC-CHARGE JC61-70925A 1 SNA
8.7-13 SPRING ETC-TORSION DOC (CC2-F) JB61-00076A 1 SA
8.8-0 ELA HOU-DADF SUB JC96-02973B 1 SNA
8.8-1 MEA UNIT-COVER OPEN JC97-01844B 1 SA
8.8-1-1 COVER-OPEN JC63-00195B 1 SA
8.8-1-2 PMO-STOPPER EXIT JC72-41396B 1 SA
8.8-1-4 ROLLER-REGI JC66-00587A 1 SNA
8.8-1-5 PMO-LEVER OPEN JC72-01256B 1 SNA
8.8-1-6 SPRING ETC-KNOCKUP,MP JC61-00483A 2 SA
8.8-1-7 PBA SUB-REGI JC92-01561A 1 SA
8.8-1-8 PMO-ACTUATOR REGI JC72-01261A 1 SNA
8.8-1-9 COVER-SENSOR JC63-00197B 1 SA
8.8-1-10 SPRING ETC-TORSION DOC (CC2-F) JB61-00076A 1 SA
8.8-1-11 BUSH-6_D JC61-00423A 2 SA
8.8-1-12 RING-E 6044-000125 3 SA
8.8-1-13 GROUND-P DUPLEX JC63-00315A 1 SNA
8.8-1-14 COVER-HARNESS JC63-00408B 1 SNA
8.8-1-15 CBF HARNESS-LIU GND JB39-00103A 1 SA
8.8-2 GUIDE-SCAN JC61-00738B 1 SNA
8.8-3 GROUND-P_SCAN ROLLER JC63-00249A 1 SNA
8.8-4 GROUND-P_EXIT ROLLER JC63-00250A 1 SNA
8.8-5 PBA SUB-SENSOR_IF JC92-01556A 1 SA
8.8-6 IPR-BRKT WHITE BAR JC70-00225A 1 SA
8.8-7 SPRING ETC-WHITE BAR JC61-00548A 2 SA
8.8-8 SHEET-GUIDE PAPER JC63-00185A 1 SNA
8.8-9 ROLLER-EXIT JC66-00588A 1 SA
8.8-10 GEAR-DADF_EXIT31 JC66-00571A 1 SA
8.8-11 MEA UNIT-COVER EXIT JC97-01841B 1 SNA
8.8-11-1 COVER-EXIT JC63-00196B 1 SNA
8.8-11-2 SPRING ETC-WHITE BAR JC61-00548A 2 SA
8.8-11-3 PMO-ROLLER IDLE SCAN JC72-00906A 3 SA
8.8-11-4 SHAFT-EXIT IDLE JC66-00661A 1 SA
8.8-11-5 TAPE ETC-ANTI BRUSH JC02-00014A 1 SNA
8.8-11-6 GROUND-P-EXIT COVER JC63-00203A 1 SNA
8.8-12 ROLLER-SCAN JC66-00585A 2 SA
8.8-13 PMO-BUSHING HOLDER JG72-40732A 2 SNA
8.8-14 SPRING ETC-CLUTCH JB61-70922A 2 SA
8.8-15 GEAR-DADF_SCAN31 JC66-00570A 2 SA
8.8-16 MEA UNIT-PICK_UP JC97-01848A 1 SA
8.8-17 MEP-CLUTCH SMALL JC47-00003C 3 SA
8.8-18 ELA HOU-DUPLEX MOTOR JC96-02940A 1 SA
8.8-19 MOTOR STEP-DUPLEX JC31-00034A 1 SA
8.8-20 IPR-GUARD C/O S/W JC70-00218A 1 SA
8.8-21 CBF HARNESS-COVER_OPEN JC39-00332A 1 SA
8.8-22 MOTOR STEP-DADF JC31-00033A 1 SA
8.8-23 ELA HOU-DADF MOTOR JC96-02941A 1 SA
8.8-24 COVER-P GEAR JC63-00307A 1 SA
8.8-26 GEAR-DADF24(A) JC66-00565A 1 SA
8.8-27 PMO-GATE DUPLEX JC72-01255A 1 SA
8.8-28 PBA SUB-DADF JC92-01554B 1 SA
8.8-29 CBF HARNESS-CLUTCH_IF JC39-00327A 1 SA
8.8-30 CBF D SUB CABLE-DADF JC39-00359A 1 SA
8.8-31 PMO-ACTUATOR SCAN JC72-01249A 1 SA
8.8-32 PMO-ACTUATOR DUPLEX JC72-01263A 1 SA

