Samsung SCX-6322DN Service Manual

Service Manual
Reference Information
12-6
Samsung Electronics
GEAR-EXIT/U,ID U=Upper
ID=Idler
IPR-TERMINAL FU FU=Fuser
PMO-BEARING H/R-F H/R-F=Heat Roller - Front
BEARING-H/R L H/R-L=Heat Roller -Left
PEX-ROLLER EXIT F_UP PEX= Processing Extrude
F_UP=Face Up
SPRING ETC-P/R P/R=Pressure Roller
SPRING(R)-CAU-HOT-FU CAU-HOT-FU = Caution Hot -Fuser
PMO-ARM ACTUATOR PMO-ARM= Processing Mold Arm
LABEL(R)-HV FUSER HV=High Voltage (220V)
LABEL(R)-LV FUSER LV=Low Voltage (110V)
PPR-SPONG SHEET PPR=Plastic Press
IPR-P_PINCH(SCAN)I PR-P = Iron Press
ROLLER-REGI REGI=Registration
PBA SUB-REGI PBA SUB-REGI => Sub Printed circuit Board
Assembly for the Registration
GROUND-P_SCAN ROLLER GROUND-P =Ground-Press
IPR-GUARD C/O S/W C/O = Cover Open
S/W= Switch
MEA UNIT-TX STACKER TX =Transmit
IPR-WASHER SPRING CU CU=Curve
