Function
--
1'st LCD 2'st LCD 3'st LCD 4'st LCD 5'st LCD 6'st LCD Default
Tech Mode 1 Data Setup [Send Level] Send Level [-9~-15] -12
Data Setup
[Modem Speed] Modem Speed
[33.6,28.8,14.4,12,96,
48]
33.6
[Dial Mode] Dial Mode [Tone, Pulse]
[Error Rate] Error Rate [5%, 10%] 10%
[Notify Toner] Notify Toner [Customer No.]
[Customer Name]
[Service Number]
[Serial Number]
[Clear All Mem.] Clear All Mem.
[Clear Count] Clear Count [Total Page Count]
[CRU Print CNT]
[FLT Scan Count]
[ADF Scan Count]
[Used Toner CNT]
[Flash Upgrade] Flash Upgrade [Local]
[Remote]
2 Machine Test [Switch Test]
[Modem Test]
[DRAM Test]
[ROM Test]
[Pattern Test]
[Shading Test]
3 Engine Test [Diagnostic] Engine Test NO > 0 - 6 ALL MOTOR TEST 1:ON 2:OFF
FCF SOLENOID TEST 1:ON 2:OFF
M F SOLENOID TEST 1:ON 2:OFF
PTL TEST 1:ON 2:OFF
FAN TEST 1:ON 2:OFF
FUSER CONTROL TEST 1:ON 2:OFF
FUSER TEMP TEST 1:CHECK 2:NEXT
LSU MOTOR TEST 1:ON 2:OFF
LASER DIODE TEST 1:ON 2:OFF
LSU READY TEST 1:CHECK 2:NEXT
LSU HSYNC TEST 1:CHECK 2:NEXT
SENSOR TEST 1:CHECK 2:NEXT
SCF MOTOR TEST 1:ON 2:OFF
SCF SOLENOID TEST 1:ON 2:OFF
SCF EMP/INST TEST 1:CHECK 2:NEXT
OPC FUSE STATE 1:CHECK 2:NEXT
OPC FUSE CHECK 1:CHECK 2:NEXT
TONER STATE 1:CHECK 2:NEXT
TONER LOW CHECK 1:CHECK 2:NEXT
PAGE COUNTER INC 1:CHECK 2:NEXT
AIR TEMP CHECK 1:CHECK 2:NEXT
MHV SUPPLY 1350V 1:ON 2:OFF
MHV ADC READ 1:CHECK 2:NEXT
DEV SUPPLY 450V 1:ON 2:OFF
THV SUPPLY NEG VOLT 1:ON 2:OFF
THV SUPPLY 1301V 1:ON 2:OFF
THV ADC READ 1:CHECK 2:NEXT
TEST START NEXT : RIGHT KEY
[Status Print]
4 DADF Test DADF EDC
[DADF Diagnostic]
Clutch Test
Motor Test
Sensor Test
5 Report [Protocol]
[System Data]
