Installation and Operation Manual
This section provides instructions for inserting
and removing NAVIONICS SD card
procedure.
Inserting the SD Card
1 Hold the SD card so that you can
see the NAVIONICS label.
2 Open the door, gently push the SD card
into the slot; push the SD card in as far as
you hear click sound, then close door.
Removing the SD Card
1 Turn off the unit.
2 Open the door and push in on the SD card
until it is released.
3 Close the door.
Insert NAVIONICS SD card
correctly.
(DO NOT FORCE)
Close SD card door firmly all
the times.
Do not remove SD card
during reading and writing.
A user can select a map between NAVIONICS
and S-MAP.
A user can select a map as follow instruction,
Chart Selection
1 Press and hold .
2 Select the system setting icon.
3 Select Chart then a chart you prefer.
NAVIONICS SD is optional.
User can purchase it
themselves or contact
Samyung agent for
purchasing.
Simulate Mode is great for practicing the
actual use of a product when the satellites
signals and internal alarms are not available.
In the simulate mode, the unit turns the GPS
receiver off and ignores data from all optional
devices..
Two simulate modes are available as below.
• Normal: Allows a user to practicing the
actual use of a product without satellites
connection.
• Demo: boat travel alone given route at
given speed and show different
function of the unit.
Do not try to navigate in a
simulate mode. While the
simulate mode is turned on,
the GPS receiver is not
active.
