The Chart plotter can display up to four
windows at the same time.
Adding a window
1 Press and select Add icon.
2 Select an icon you want to add.
3 Repeat above steps if necessary.
Changing window size
1 Press and select Split icon on
bottom.
2 Press
or to change the height of
the windows if there is only two windows. If
the unit is displaying more that three
windows, press , ,
or
to
change the height of the windows.
Deleting a window
1 Press and hold
to select a window
you want to delete.
2 Press and select Remove icon to
remove.
Replacing two windows on the
display
1 Press and hold to active desired
window you want to replace.
2 Press , select Replace icon.
3 Select icon you want to display then press
.
