Installation and Operation Manual
3-4-11 Distance and bearing calculator
The unit can show the bearing and the length
of leg and the total distance of legs.
Setting Legs
1 In the chart window, press
and
select Distance. Information is displayed
on window showing bearing/leg
distance/total distance at bottom pop up
at the bottom left side
2 Move the cursor to the start point which is
start point of first leg and press .
3 Move the cursor to a point which is the end
of first leg.
4 Repeat 2-3 steps for more legs.
5 Press to exit.
Deleting the last leg
1 Press and select Remove.
2 Repeat above step if you want to remove
more legs.
Saving as a route
1 Once you set all the legs, press and
select Save.
2 Enter a route name by pressing or
to select a letter then press for next
letter.
3 Press to save the new route.
Tip: Bearing and distance
The projected course shows you how far it
can go at give time and speed.
This function is very useful to avoid collusion
with other vessels.
3-4-13 Finding a chart symbol
In the chart window, press and hold
then select destination chart symbol.
