Santerno DCREG4.150 - P013: Max. Positive Speed; Voltage Reference; P014: Min. Positive Speed; Voltage Reference; P015: Max. Negative Speed; Voltage Reference

15P0059B3 DCREG2
USER MANUAL DCREG4
136/200
7.2.11 P013: MAX. POSITIVE SPEED / VOLTAGE REFERENCE
P013 nMaxPos
P
P013 - nMaxPos
*** %
R
0 ... 100 %
D
100 %
F
This parameter sets, as a percentage of the max. reference corresponding to
10V, the max. allowable value both for the Ref n reference applied to the ramps
and for the n setpoint global positive speed / voltage reference resulting from the
algebraic sum of all the applied references.
This parameter may be used to limit the speed set in the running direction at
issue.
WARNING
In this parameter, do not save any lower value than the one saved in
EEPROM for P014, as this will cause the drive malfunction.
7.2.12 P014: MIN. POSITIVE SPEED / VOLTAGE REFERENCE
P014 nMinPos
P
P014 - nMinPos
*** %
R
0 ... 100 %
D
0 %
F
This parameter sets, as a percentage of the max. reference corresponding to
10V, the min. allowable value both for the Ref n reference applied to the ramps
and for the n setpoint global positive speed / voltage reference, even if no
reference is applied or if negative references are applied. In this parameter, in
order to enter a min. reference you need to program P012 = 1:Positive only first.
Anyway, disabling of minimum speed can be achieved by closing the digital
input set to the 9:MinSpdDisabled function (see parameter set C130 ... C135).
WARNING
In this parameter, do not save any value exceeding the one saved in
EEPROM for P013, as this will cause the drive malfunction.
WARNING
If a value of P012  1 is saved in EEPROM, do not save any value other than
zero for this parameter, as this will cause the drive malfunction.
7.2.13 P015: MAX. NEGATIVE SPEED / VOLTAGE REFERENCE
P015 nMaxNeg
P
P015 - nMaxNeg
**** %
R
-100 ... 0 %
D
-100 %
F
This parameter sets, as a percentage of the max. reference corresponding to
10V, the max. allowable absolute value both for the Ref n reference applied to
the ramps and for the n setpoint global negative speed / voltage reference
resulting from the algebraic sum of all the applied references.
WARNING
In this parameter, do not save - as an absolute value - any value exceeding
the one saved in EEPROM for P016, as this will cause the drive malfunction.
This parameter may be used to limit the speed set in the running direction at
issue.
