15P0059B3 DCREG2
USER MANUAL DCREG4
56/200
3.24 DCREG MODULAR.S CONTROL UNIT TERMINALS
Decisive voltage class C according to EN 61800-5-1
G1A A bridge TH1 thyristor gate (to terminal G1A of the Control Unit)
K1A A bridge TH1 thyristor cathode (to terminal K1A of the Control Unit)
G2A A bridge TH2 thyristor gate (to terminal G2A of the Control Unit)
K2A A bridge TH2 thyristor cathode (to terminal K2A of the Control Unit)
G3A A bridge TH3 thyristor gate (to terminal G3A of the Control Unit)
K3A A bridge TH3 thyristor cathode (to terminal K3A of the Control Unit)
G4A A bridge TH4 thyristor gate (to terminal G4A of the Control Unit)
K4A A bridge TH4 thyristor cathode (to terminal K4A of the Control Unit)
G5A A bridge TH5 thyristor gate (to terminal G5A of the Control Unit)
K5A A bridge TH5 thyristor cathode (to terminal K5A of the Control Unit)
G6A A bridge TH6 thyristor gate (to terminal G6A of the Control Unit)
K6A A bridge TH6 thyristor cathode (to terminal K6A of the Control Unit)
G1B B bridge TH1 thyristor gate (to terminal G1B of the Control Unit)
K1B B bridge TH1 thyristor cathode (to terminal K1B of the Control Unit)
G2B B bridge TH2 thyristor gate (to terminal G2B of the Control Unit)
K2B B bridge TH2 thyristor cathode (to terminal K2B of the Control Unit)
G3B B bridge TH3 thyristor gate (to terminal G3B of the Control Unit)
K3B B bridge TH3 thyristor cathode (to terminal K3B of the Control Unit)
G4B B bridge TH4 thyristor gate (to terminal G4B of the Control Unit)
K4B B bridge TH4 thyristor cathode (to terminal K4B of the Control Unit)
G5B B bridge TH5 thyristor gate (to terminal G5B of the Control Unit)
K5B B bridge TH5 thyristor cathode (to terminal K5B of the Control Unit)
G6B B bridge TH6 thyristor gate (to terminal G6B of the Control Unit)
K6B B bridge TH6 thyristor cathode (to terminal K6B of the Control Unit)
Decisive voltage class A according to EN 61800-5-1
P0 Thermo-switches series common (to terminal P0 of the Control Unit)
PT Thermo-switches series NC (to terminal PT of the Control Unit)
Decisive voltage class C according to EN 61800-5-1
L1 L1 bar potential (Note 1)
L2 L2 bar potential (Note 1)
L3 L3 bar potential (Note 1)
A1 A1 bar potential (to terminal A1 of the Control Unit)
A2 A2 bar potential (to terminal A2 of the Control Unit)
Decisive voltage class A according to EN 61800-5-1
COM Current transformers common (to terminal COM of the Control Unit)
TAR TAR current transformer output (to terminal TAR of the Control Unit)
TAT TAT current transformer output (to terminal TAT of the Control Unit)
N.B.: TH1B .. 6B thyristors in DCREG4 type only.
(1) Note: Terminals L1-L2-L3 in the Control Unit are to be respectively connected to terminals L1-L2-
L3 in the Power Unit in case of a mains up to 500 Vac, whereas they have to be directly
connected to the secondary in three-phase transformer TS in case of a mains exceeding 500
Vac. In the latter case, terminals L1-L2-L3 in the Power Unit have to be left disconnected.
