15P0059B3 DCREG2
USER MANUAL DCREG4
58/200
Note (1): For UL application field use “75 °C copper wire only” or equivalent.
Note (2): If the control section is to be supplied with a single-phase alternating voltage, the max.
voltage to be applied to terminals 53-54 is 500 Vac. For the mains up to 690 Vac,
ELETTRONICA SANTERNO may supply a single-phase, 700/500 V transformer, 150 VA,
P/N TR0112260.
