SY75C Excavator OMM Machine Decals
SANY Operation and Maintenance Manual — 0220 2-13
TABLE OF
CONTENTS
INTRODUCTIONSAFETY
MACHINE
CONTROLS
MACHINE
OPERATION
MAINTENANCESPECIFICATIONS
OPTIONAL
EQUIPMENT
7. Fire extinguisher
• Located inside the cab on the upper level of the
back window.
• Shows the location of the fire extinguisher on the
machine.
8. Front window warning
• Located on the upper right corner of the front
window.
• Gives warning to make sure the front window is
locked in place.
9. Grease point pressure warning
• Located next to the opening for the track tensioning
grease point on either side of the tracks.
• Warns about grease spraying out under pressure
from the track tensioner.
10. High temperature warning
• Located in the engine compartment near the exhaust
piping.
• Warns about high temperature areas, keep away
from hot components and the possibility of burns.
Fig. 2-11
Fig. 2-12
Fig. 2-13
Fig. 2-14
