Bottom
Back
①Indicators
②Top Cover
③ Top Cover Release Button
④Infrared Remote Receiver (Front)
⑤ Projection Lens (optional)
⑥Light-Block Sheet
⑦ Adjustable Feet
⑧ Air Intake Vent
⑨ Filter Cover
⑩ Lamp Cover
⑪Exhaust Vent
CAUTION
Hot air is exhausted from the exhaust
vent. Do not put heat-sensitive objects
near this side.
⑫ Terminals and Connectors
⑬ Infrared Remote Receiver (Back)
⑭ Power Cord Connector
⑮ Optional Parts Attachment
⑯Side Controls
⑰Hand Grip
Front
③
②
①
④ ⑩
⑨
⑥
⑧
⑤
⑦
⑰
⑦
⑪
⑬
⑫
⑮
⑭
⑯
