When replacing the lens or using an optional lens, install the lens by following the instructions below. Ask
the sales dealer for detailed information of the optional lens specifications.
Shift the lens to the center position by using the
Lens shift function (p.
27
).
1
2
Removing the lens
Top cover release button
CAUTION
Be careful when handling the lens. Do not
drop.
3
4
Top cover
Light-block
sheet
While pressing the top cover release button on
the top cover, slide the top cover toward front
to remove it.
Slide the light-block sheet upward and remove
it.
Hold the lens with one hand and pull the
Lens Lock Lever upward with the other hand.
Remove the lens from the projector.
]Do not touch the glass part of the lens with
your hand.
5
Turn off the projector and unplug the AC power
cord.
Lens Installation
To Next Page
