-106-
Parts Location Diagrams
KA8-XM15000 / KA8-XM150L00
KZ5-XM10000 / KZ5-XM100L00
In the optical unit
L11
L07
L17
L06
L16
L05
CAUTION:
Part must be placed in specified direction when replacing the optical parts. Please see “Optical Parts
Disassembly” for further instructions.
