Sanyo PLC-XM150L User Manual

-4-
Specifications
This symbol on the nameplate means the product is Listed by Underwriters
Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety stan-
dards against risk of fire, casualty and electrical hazards.
Mechanical Information
Projector Type Multi-media Projector
Dimensions (W x H x D) PLC-XM100L/PLC-XM150L: 19.25” x 6.46” x 14.61” (489.5 mm x 164.0 mm x 371.1 mm)
PLC-XM100/PLC-XM150 : 19.25” x 6.46” x 17.12” (489.5 mm x 164.0 mm x 434.8 mm)
Net Weight PLC-XM100L/PLC-XM150L: 19.6 lbs (8.9 kg)
PLC-XM100/PLC-XM150 : 21.3 lbs (9.7 kg)
Feet Adjustment 0˚ to 4˚
Panel Resolution
LCD Panel System 0.8” TFT Active Matrix type, 3 panels
Panel Resolution 1,024 x 768 dots
Number of Pixels 2,359,296 (1,024 x 768 x 3 panels)
Signal Compatibility
Color System PAL, SECAM, NTSC, NTSC4.43, PAL-M, and PAL-N
SD/HD TV Signal 480i, 480p, 575i, 575p, 720p, 1035i, 1080i and 1080p
Scanning Frequency H-sync. 15 kHz–100 kHz, V-sync. 48 Hz–100 Hz
Optical Information
Projection Image Size (Diagonal) Adjustable from 40” to 400” (PLC-XM100/PLC-XM150)
Throw Distance 4.3' (1.30m) - 75.4' (22.99m) (PLC-XM100/PLC-XM150)
Projection Lens F1.7–2.3 lens with f=26.9 mm–45.4 mm with motor zoom and focus
(PLC-XM100/PLC-XM150)
Projection Lamp PLC-XM150L/PLC-XM150: 330 W NSHA lamp
PLC-XM100L/PLC-XM100: 275 W NSHA lamp
Interface
Input 1 Digital (DVI-D) x 1, Analog (Mini D-sub 15 pin) x 1
Input 2 BNC Type x 5 (G or Video/Y, B or Pb-Cb, R or Pr-Cr, HV and V)
Input 3 RCA Type x 3 (Video/Y, Pb/Cb,Pr/Cr), Mini DIN 4 pin x 1 (S-video)
Analog Out Analog RGB (Mini D-sub 15 pin) Terminal x 1
Audio Out Audio (Mini Type stereo) x 1
Audio In 1/2 Audio (Mini Type stereo) x 1
Audio In 3 RCA Type x 2
R/C Jack Mini jack (Wired Remote) x 1
Control Port D-sub 9 pin x 1
USB Connector USB Series B x 1
Option PJ-Net Organizer Terminal x 1
LAN Connection Terminal RJ45
Audio
Internal Audio Amp 7.0 W RMS
Built-in Speaker 1 speaker, ø1.46" (37mm)
Power
Voltage and Power Consumption AC 100–120 V (5.2A Max. Ampere), 50/60 Hz (The U.S.A and Canada)
AC 200–240 V (2.5A Max. Ampere), 50/60 Hz (Continental Europe and The U.K.)
Operating Environment
Operating Temperature 41˚F–104˚F (5˚C–40˚C)
Storage Temperature 14˚F–140˚F (-10˚C–60˚C)
Remote Control
Battery AAA or LR03 Type x 2
Operating Range 16.4’ (5 m/±30˚)
Dimensions 1.8” (W) x 1.0” (H) x 5.7” (D) (45 mm x 25 mm x 145 mm)
Net Weight 3.5 oz (99 g) (including batteries)
Accessories
Owner’s Manual (CD-ROM) Lens Cap (for PLC-XM100/PLC-XM150)
Quick Reference Guide Lens Mount Cover (for PLC-XM100L/PLCXM150L)
AC Power Cord Lens Antitheft screw *
Remote Control and Batteries VGA Cable
USB Cable PIN Code Label
● The specifications are subject to change without notice.
● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a tiny
fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels.

Sanyo PLC-XM150L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
