Sanyo PLC-XM150L User Manual

-64-
DVI-D
INPUT1INPUT2MONITOR
OUTPUT
D_SUB
PJ-Net
BNCD_SUB
CONTROL
PORT
D_SUB RCA
USB
S-VIDEO
F-RC
T-RC
IC1101
SYNC SEP.
IC3801
RS-232C
IC2813
OR
IC2201
A/D
IC5201
PC/PJ-NET
SW
IC1311 IC1331
DDR
MEMORY
IC4801
I/O
EXPANDER
IC301
SYSTEM
CONTROL
&
SCAN
CONVERTER
IC501
B-S/H
G-LCD
PANEL
B-LCD
PANEL
IC531
G-S/H
IC561
R-S/H
MOTOR
CONTROL
FAN
CONTROL
LED
DRIVE
IC801
FLASH
MEMORY
IC1692
TEMP
SENSOR A
IC1816
TEMP
SENSOR B
IC1814
TEMP
SENSOR C
IC401
DIGITAL
GAMMA
H/V
R/G/B OUT H/V OUT
RC_ALL
POWER_SW
SCART_R/G/B COMPONENT
S-C/S-Y
USB+,-
INPUT3
AUDIO
IN1 IN2
OUT
IN3
IC5001
AUDIO
SELECTOR
FOCUS/ZOOM FANS
M
MOTOR
CONTROL
LENS SHIFTM
LEDS
(PANEL)
IC886
PRESS
SENSOR
IC3850
ACCELERA-
TION(0~180)
SENSOR
IC1884
ACCELERA-
TION (-1~-180)
SENSOR
(LAMP)(ROOM)
IC1387
EEPROM
D[0-7] A[0-7]
RAOUT GAOUT BAOUT
IC2301
KEYSTONE
PW_DR PW_DB PW_DG
IC2001
SELECTOR
IC9885
SUB-MICON
IC5231
ANALOG
SW
IC5271
ANALOG
SW
S901
WIND
SENSOR
R-LCD
PANEL
IC6502/IC6521
LENS SHIFT
MOTOR
CONTROL
FILTERM
IC5541
FILTER
IC5501/IC5521
FOCUS/ZOOM
IC5561
SHUTTER
SHUTTER
CONTROL
SHUTTER
M
W-RC
R-RC
IC2810
INVERTER
IC2811
BUFFER
SW
IC8001
DVI
RECEIVER
Chassis over view
Troubleshooting

Sanyo PLC-XM150L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
