-63-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
5 Clamp 0 - 255 80
6 Clamp Width 0 - 255 31
555 RGB Video (1080PSF - 30)
0 Total Dots (Read only) 0 - 4095 2200
1 Disp Dots 0 - 4095 1882
2 H Back Porch 0 - 4095 228
3 V Back Porch 0 - 4095 56
4 Disp Line 0 - 4095 1048
5 Clamp 0 - 255 80
6 Clamp Width 0 - 255 31
556 RGB Video (1080PSF - 25)
0 Total Dots (Read only) 0 - 4095 2640
1 Disp Dots 0 - 4095 1874
2 H Back Porch 0 - 4095 248
3 V Back Porch 0 - 4095 54
4 Disp Line 0 - 4095 1052
5 Clamp 0 - 255 80
6 Clamp Width 0 - 255 31
557 RGB Video (1080PSF - 24)
0 Total Dots (Read only) 0 - 4095 2750
1 Disp Dots 0 - 4095 1890
2 H Back Porch 0 - 4095 242
3 V Back Porch 0 - 4095 54
4 Disp Line 0 - 4095 1048
5 Clamp 0 - 255 64
6 Clamp Width 0 - 255 31
