Sanyo PLC-XM150L User Manual

-62-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
544 RGB Video (720P - 60 )
0 Total Dots 0 - 4095 1650
1 Disp Dots 0 - 4095 1248
2 H Back Porch 0 - 4095 315
3 V Back Porch 0 - 4095 34
4 Disp Line 0 - 4095 700
5 Clamp 0 - 255 110
6 Clamp Width 0 - 255 31
545 RGB Video (720P - 50 )
0 Total Dots 0 - 4095 1980
1 Disp Dots 0 - 4095 1248
2 H Back Porch 0 - 4095 306
3 V Back Porch 0 - 4095 34
4 Disp Line 0 - 4095 700
5 Clamp 0 - 255 110
6 Clamp Width 0 - 255 31
546 RGB Video (1080i - 60)
0 Total Dots 0 - 4095 2200
1 Disp Dots 0 - 4095 1872
2 H Back Porch 0 - 4095 250
3 V Back Porch 0 - 4095 54
4 Disp Line 0 - 4095 1052
5 Clamp 0 - 255 80
6 Clamp Width 0 - 255 31
547 RGB Video (1080i - 50)
0 Total Dots 0 - 4095 2640
1 Disp Dots 0 - 4095 1870
2 H Back Porch 0 - 4095 252
3 V Back Porch 0 - 4095 52
4 Disp Line 0 - 4095 1052
5 Clamp 0 - 255 80
6 Clamp Width 0 - 255 31
548 RGB Video (1035i)
0 Total Dots 0 - 4095 2200
1 Disp Dots 0 - 4095 1872
2 H Back Porch 0 - 4095 252
3 V Back Porch 0 - 4095 90
4 Disp Line 0 - 4095 1012
5 Clamp 0 - 255 80
6 Clamp Width 0 - 255 31
551 RGB Video (1080P - 30)
0 Total Dots 0 - 4095 2200
1 Disp Dots 0 - 4095 1874
2 H Back Porch 0 - 4095 250
3 V Back Porch 0 - 4095 55
4 Disp Line 0 - 4095 1051
5 Clamp 0 - 255 80
6 Clamp Width 0 - 255 31
552 RGB Video (1080P - 25)
0 Total Dots 0 - 4095 2640
1 Disp Dots 0 - 4095 1874
2 H Back Porch 0 - 4095 250
3 V Back Porch 0 - 4095 56
4 Disp Line 0 - 4095 1051
5 Clamp 0 - 255 80
6 Clamp Width 0 - 255 31
553 RGB Video (1080P - 24)
0 Total Dots (Read only) 0 - 4095 2750
1 Disp Dots 0 - 4095 1874
2 H Back Porch 0 - 4095 250
3 V Back Porch 0 - 4095 56
4 Disp Line 0 - 4095 1051

Sanyo PLC-XM150L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
