Sanyo PLC-XM150L User Manual

-71-
Troubleshooting
DVI-D
INPUT1
NETWORKD_SUB15
INPUT2
BNC
RCAS-VIDEO
INPUT3
SCART_R
HSOUT
VSOUT
SCART_G
SCART_B
S-C_PW
S-Y_PW
-BNC/RCA
IC2001
SELECTOR
<AD8183>
AV MAIN
K21A
K21A
K10A
K10A
IC301
SYSTEM
CONTROL
&
SCAN
CONVERTER
<PW392>
IC1011
SYNC
SEP.
<BA7078>
343 213 105 104 214 106 215
98
399
18
109 210 209 311 139 198 318
IC5201
PC
/PJ-NET SW
FPGA
<XC3S50A>
IC2201
A/D
ISL98001
IC5231
ANALOG-SW
<THS7347>
IC5271
ANALOG-SW
<THS7347>
IC8001
DVI
RECEIVER <SII9127>
Y_IN
G_IN G_IN
B_IN
HS1
VS1
HS
VS
R_IN
G_PC
B_PC R_PC
CR_IN CB_IN
Y_IN_PW
VIDEO
CR_IN_PW CB_IN_PW
R_BNC
G_BNC
B_BNC
INPUT2_HS
INPUT2_VS
D_SUB15
MONITOR
OUT
IC261
SCART_CV_PW
Q1004 ~ Q1345
IC4002
BUFFER
OUT_HS
OUT_VS
8,10,12
1,3,5
1,2,3 1,2,3
27, 32,36 25,24
36
46 44 42
13 7
311
44
CG_R [8bit] CG_G [8bit] CG_B [8bit]
IN0R [10bit] IN0G [10bit] IN0B [10bit]
33
7
IN0HS
133
IN0VS
240
12 19
32 27 25 24
SCART_CV
4,5
4,5
7,8,9
2,5
2 5
3
7 8 9
10 11
20 18 16 22
1
18,12,14 13,17
9 5 8
25 21
COMPONENT
COMPONENT
HV RGB
RGB
RGB
HV
HV
OUT_R/CR OUT_B/CB
OUT_G/Y
No Picture

Sanyo PLC-XM150L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
