Key No. Part No. Description Key No. Part No. Description
-111-
Electrical Parts List
KA8-XM15000 / KA8-XM150L00
KZ5-XM10000 / KZ5-XM100L00
ASSEMBLED BOARDS
For PLC-XM150L / PLC-XM150
A1000 655 003 1051 ASSY,PWB,MAIN KA8AL
A1600 655 003 1044 ASSY,PWB,SENSOR C KA8AL
A1800 655 003 1037 ASSY,PWB, SENSOR A KA8AL
A1880 655 003 1020 ASSY,PWB,AMF SENSOR KA8AL
A1890 655 003 1013 ASSY,PWB,FILTER SW KA8AL
A8730 655 003 1006 ASSY,PWB,ID CONNECT KA8AL
A2000 655 003 0979 ASSY,PWB,A/V KA8AL
A3600 655 003 0962 ASSY,PWB,NET JOINT KA8AL
A6800 655 003 0955 ASSY,PWB,F/T RC+LED KA8AL
A6870 655 003 0948 ASSY, PWB ,CONTROL KA8AL
AA600 655 003 0924 ASSY, PWB, POWER KA8AL
For PLC-XM100L / PLC-XM100
A1000 655 003 4601 ASSY,PWB,MAIN KZ5AL
A1600 655 003 1044 ASSY,PWB,SENSOR C KA8AL
A1800 655 003 1037 ASSY,PWB, SENSOR A KA8AL
A1880 655 003 1020 ASSY,PWB,AMF SENSOR KA8AL
A1890 655 003 1013 ASSY,PWB,FILTER SW KA8AL
A8730 655 003 1006 ASSY,PWB,ID CONNECT KA8AL
A2000 655 003 0979 ASSY,PWB,A/V KA8AL
A3600 655 003 0962 ASSY,PWB,NET JOINT KA8AL
A6800 655 003 0955 ASSY,PWB,F/T RC+LED KA8AL
A6870 655 003 0948 ASSY, PWB ,CONTROL KA8AL
AA600 655 003 0924 ASSY, PWB, POWER KA8AL
OUT OF CIRCUIT BOARD
For PLC-XM150L/PLC-XM150
! LP901 610 346 9607 COMPL,OPT LMP-KA8AL
! A901 645 093 0980 UNIT,BALLAST
A901A 610 349 4319 CABLE,BALLAST SERVICE KA8AL
! FN903 645 101 9707 MOTOR,BLW DC ***W
! FN904 645 101 9738 MOTOR,BLW DC ***W
For PLC-XM100L/PLC-XM100
! L901 610 347 5158 COMPL,OPT LMP-KZ5AL
! A901 610 349 5538 UNIT, BALLAST SERVICE
! FN903 645 102 2066 MOTOR,BLW DC ***W
! FN904 645 102 2073 MOTOR,BLW DC ***W
Common
L901 945 033 2228 CORE,FERRITE
L902 645 063 6905 CORE,CLAMP
L903 945 023 4959 CORE,CLAMP
L904 945 003 3835 CORE,FERRITE
L905 945 023 4959 CORE,CLAMP
! FN901 645 101 9752 MOTOR,FAN DC 2.16W
! FN902 645 101 9745 MOTOR,BLW DC ***W
! FN905 645 101 9769 MOTOR,FAN DC 2.52W
! FN906 645 101 9721 MOTOR,BLW DC ***W
! FN907 645 101 9714 MOTOR,BLW DC ***W
! FN908 645 101 9714 MOTOR,BLW DC ***W
! FN909 645 101 9691 MOTOR,BLW DC ***W
! FN910 645 101 9684 MOTOR,BLW DC ***W
! FN911 645 101 9684 MOTOR,BLW DC ***W
K11A1 312 073 0406 SPECIAL SCREW
K11A2 312 073 0406 SPECIAL SCREW
K11B1 312 073 0406 SPECIAL SCREW
K11B2 312 073 0406 SPECIAL SCREW
K14A1 312 073 0406 SPECIAL SCREW
K14A2 312 073 0406 SPECIAL SCREW
K38A1 312 073 0406 SPECIAL SCREW
K38A2 312 073 0406 SPECIAL SCREW
M901 645 093 2571 MOTOR,DC 12V
S901 645 093 2533 UNIT,WIND VELOCITY SENSOR
SP901 652 002 6445 SPEAKER,8
! SW902 652 003 0954 SWITCH,THERMAL
Z6B&SW 652 003 0961 ASSY,WIRE (SW901)
! Z8B&SW 652 003 0862 ASSY,WIRE (SW902)
For PLC-XM150L / PLC-XM150
A1000 655 003 1051 ASSY,PWB,MAIN KA8AL
For PLC-XM100L / PLC-XM100
A1000 655 003 4601 ASSY,PWB,MAIN KZ5AL
TRANSISTOR
Q013 406 021 7804 TR 2SC4617
Q014 406 021 7804 TR 2SC4617
Q036 406 021 7804 TR 2SC4617
Q037 406 021 7804 TR 2SC4617
Q1001 305 217 4913 TR RN1111 TE85L
Q1002 305 217 4913 TR RN1111 TE85L
Q1003 305 217 4913 TR RN1111 TE85L
Q1004 406 021 7804 TR 2SC4617
Q1008 406 021 7804 TR 2SC4617
Q1009 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1011 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1012 406 021 7804 TR 2SC4617
Q1013 406 021 7804 TR 2SC4617
Q1341 406 021 7804 TR 2SC4617
Q1342 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1343 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1344 406 021 7804 TR 2SC4617
Q1345 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F

Sanyo PLC-XM150L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
