-60-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
2 H Back Porch 0 - 4095 316
3 V Back Porch 0 - 4095 34
4 Disp Line 0 - 4095 700
5 Clamp 0 - 255 183
6 Clamp Width 0 - 255 20
526 YCbCr (1080i - 60)
0 Total Dots 0 - 4095 2200
1 Disp Dots 0 - 4095 1874
2 H Back Porch 0 - 4095 258
3 V Back Porch 0 - 4095 50
4 Disp Line 0 - 4095 1050
5 Clamp 0 - 255 168
6 Clamp Width 0 - 255 20
527 YCbCr (1080i - 50)
0 Total Dots 0 - 4095 2640
1 Disp Dots 0 - 4095 1872
2 H Back Porch 0 - 4095 258
3 V Back Porch 0 - 4095 50
4 Disp Line 0 - 4095 1052
5 Clamp 0 - 255 168
6 Clamp Width 0 - 255 20
528 YCbCr (1035i)
0 Total Dots 0 - 4095 2200
1 Disp Dots 0 - 4095 1874
2 H Back Porch 0 - 4095 258
3 V Back Porch 0 - 4095 90
4 Disp Line 0 - 4095 1006
5 Clamp 0 - 255 168
6 Clamp Width 0 - 255 20
529 YCbCr (1080P-60)
0 Total Dots 0 - 4095 1100
1 Disp Dots 0 - 4095 936
2 H Back Porch 0 - 4095 127
3 V Back Porch 0 - 4095 52
4 Disp Line 0 - 4095 1052
5 Clamp 0 - 255 88
6 Clamp Width 0 - 255 16
530 YCbCr (1080P-50)
0 Total Dots 0 - 4095 1320
1 Disp Dots 0 - 4095 934
2 H Back Porch 0 - 4095 128
3 V Back Porch 0 - 4095 52
4 Disp Line 0 - 4095 1052
5 Clamp 0 - 255 88
6 Clamp Width 0 - 255 16
531 YCbCr (1080P-30)
0 Total Dots 0 - 4095 2200
1 Disp Dots 0 - 4095 1868
2 H Back Porch 0 - 4095 260
3 V Back Porch 0 - 4095 46
4 Disp Line 0 - 4095 1066
5 Clamp 0 - 255 162
6 Clamp Width 0 - 255 31
532 YCbCr (1080P-24)
0 Total Dots 0 - 4095 2640
1 Disp Dots 0 - 4095 1872
2 H Back Porch 0 - 4095 258
3 V Back Porch 0 - 4095 48
4 Disp Line 0 - 4095 1064
5 Clamp 0 - 255 140
6 Clamp Width 0 - 255 31
533 YCbCr (1080P-24)

Sanyo PLC-XM150L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
