-87-
I/O Expander (TE7783, IC4801)
PIN PORT SIGNAL FUNCTION I/O NOTE
3 P2 NET_SW_PW PJNET Switch Output O
4 P3 IC_RESET Low Power Switch O H: On
5 P4 F_MOTOR_SW Filter Motor Drive O L: Output, H: Stop
6 P5 LENS_LR_SW Lens Shift LR Switch O
7 P6 LENS_UD_SW Lens Shift U/D Switch O L: Down
8 P7 PJ_UPDATE PJNET Firmware update O H: Normal Mode
9 P8 NET_H/L PJNET O Active L
49 P22 PROG_B_FRT SW_FPGA Config O
50 P23 DDC_SCL IIC Bus DDC O
51 P24 DDC_SDA IIC Bus DDC I/O
52 P25 GAMMA_SCL IIC Bus GAMMA O
53 P26 GAMMA_SDA IIC Bus GAMMA I/O
54 P27 USBB_VBUS IO USB
55 P28 USBB_D+ IO USB
61 AIN[1] PF_S1.2V_FRT Power Fail Input for S1.2V FRT I
62 AIN[2] PF_S5V_MAIN Power Fail Input for S5V MAIN I
63 AIN[3] PF_5V_MAIN Power Fail Input for 5V MAIN I
64 AIN[4] P_FAIL_LAN Power Fail Input for LAN I
65 AIN[5] ACCELE_SENS1+ Acceleration Sensor Input 1+ I
66 AIN[6] ACCELE_SENS1- Acceleration Sensor Input 1- I
67 AIN [7] ACCELE_SENS2+ Acceleration Sensor Input 2+ I
68 AIN[8] ACCELE_SENS2- Acceleration Sensor Input 2- I
72 P31 I/O_PJ_UART UART for PJNET IO UART
73 P32 PJ_I/O_UART UART for PJNET IO UART
74 P33 MOUSE_TXD PJNET Mouse IO UART
76 P35 LENS_LR_PWM Lens Shift L/R Control PWM O L: Operating, H: Stop
77 P36 LENS_UD_PWM Lens Shift U/D Control PWM O L: Operating, H: Stop
78 P37 MOTOR_STEP Filter Motor Drive O PWM
91 P11 SCLK_FRT SW FPGA Config O 3-Wire
92 P12 SDAT_FRT SW FPGA Config O 3-Wire
94 P14 BOX_SW Network Box Switch I L: Detected
97 P15 RC_W_SW Wired Remote Control Detect Input I L: Detected
99 P17 INT_FRT SW FPGA Config O
100 P18 DONE_FRT SW FPGA Config O
Control Port Functions
PIN PORT SIGNAL FUNCTION I/O NOTE
T2 SCART_G Green Signal Scart Input (Sync On G) I
U1 Y_IN_PW Y Signal Input (Component) I
U2 Y_IN_PW Y Signal Input (Component) I
U3 CB_IN_PW CB Signal Input I
V2 CR_IN_PW CR Signal Input I
Y1 HS2 Horiz. Sync Signal Output 2 O
AB3 ON_5V ON_5V Drive Signal Output O
AB4 VS2 Vert. Sync Signal Output 2 O
AG10 FILTER_COUNT Filter Scroll Count Input I
AG11 PW_R/C_FRONT RC Input Front I
AG12 EX_PW_UART UART RXD I
AG18 PW_DHS Horiz. Sync Signal Output O
AH10 PW_R_C_TOP RC Input Top I
AH11 RC_R&W_WIRED RC Input Rear and Wired I
AH12 PW_EX_UART UART_TXD O
AH18 PW_DVS Vert. Sync Signal Output O
AH21 OPTION2 Option Input I
AH22 PRESS_SENS Pressure Sensor Input I
AJ20 OPTION3 Option Input I
AJ21 OPTION1 Option Input I
AJ22 LENS_CH_POSI_EX Lens Shift H Center Position Detect I
AK21 WINDS_SENS Wind Sensor Input I
AK22 LENS_CV_EX Lens Shift V Center Position Detect I
