Sanyo PLC-XP57L User Manual

10
PREPARATION
ADJUSTABLE FEET
INSTALLING PROJECTOR IN PROPER POSITION
Install the projector properly. Improper installation may reduce the lamp life and cause a fire hazard.
Do not tilt the projector more than 10 degrees from side to side.
Do not put the projector on either side to project an image.
NO SIDEWAYS
10˚
10˚
ADJUSTABLE FEET FEET LOCK
LATCHES
Projection angle can be adjusted up to 10.5 degrees with the
ADJUSTABLE FEET.
Lift the front of the projector and pull the FEET LOCK
LATCHES in each side of the projector.
1
Release the FEET LOCK LATCHES to lock the
ADJUSTABLE FEET and rotate the ADJUSTABLE FEET to a
proper height, and tilt.
2
To retract the ADJUSTABLE FEET, lift the front of the
projector and pull and undo the FEET LOCK LATCHES.
Keystone distortion of the projected image can be corrected
by the Menu Operation. (See pages 22, 38.)
3
20˚
20˚
When projecting vertically (up or down), keep the projector’s tilt within 10 degrees.
Tilting more than 10 degrees in either direction may affect the projector life.
10˚ 10˚
10˚ 10˚

Sanyo PLC-XP57L Specifications

General

Number of colors	1.073 billion colors
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Resolution	2359296 pixels
Aspect ratio	4:3
Dimensions (WxDxH)	319 x 429.5 x 168 mm
Power requirements	100-240 V AC, 50/60 Hz
Lamp type	UHP
Lamp power	318 W
Light source type	Lamp
Noise level	36 dB
Dot clock scanning frequency	180 MHz
Analog signal format system	NTSC, NTSC 4.43, PAL, SECAM
Audio (L/R) in	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
VGA (D-Sub) ports quantity	5
Component video (YPbPr/YCbCr) in	3
Power consumption (standby)	15 W
Power consumption (typical)	480 W

Weight and Dimensions

Weight	7900 g
