18
BEFORE OPERATION
HOW TO OPERATE ON-SCREEN MENU
You can control and adjust this projector with On-Screen
Menu. Refer to the relevant pages to operate each
adjustment.
2. MOVING POINTER
3. SELECT ITEM
Move the pointer (✽ see below) or adjust a value of an item by
pressing the POINT buttons on the top control or on the remote
control.
Select an item or set the selected function by pressing the
SELECT button.
ON-SCREEN MENU
✽ The Pointer is an icon in the On-Screen Menu for selecting
an item. See figures in “FLOW OF ON-SCREEN MENU
OPERATION” below.
Used to select the item.
SELECT BUTTON
Used to move the
Pointer UP/ DOWN/
RIGHT/ LEFT.
POINT BUTTONS
TOP CONTROL
MENU BAR MENU ICON
SELECT
BUTTON
1. DISPLAY MENU
Press the MENU button to display the On-Screen Menu.
FLOW OF ON-SCREEN MENU OPERATION
Display ON-SCREEN MENU
Press the MENU button to display the On-Screen Menu
(a MENU BAR). A red frame is a POINTER.
Move the POINTER (red frame) to a MENU ICON that
you want to select by pressing the POINT RIGHT/LEFT
buttons.
Adjust the ITEM DATA by pressing the POINT
RIGHT/LEFT buttons.
Refer to the relevant pages for details of respective
adjustments.
Press the POINT UP/DOWN buttons and move the
POINTER (red frame or red arrow) to an ITEM that you
want to adjust, and then press the SELECT button to
show the ITEM DATA.
Select Menu to be adjusted
Control or adjust items through ON-SCREEN MENU
1
2
4
3
POINTER (red frame)
Press the POINT UP/DOWN
buttons to move the POINTER.
POINTER
(red frame)
ITEM
ITEM DATA
Press the POINT LEFT/RIGHT
buttons to adjust a value or set a
function.
MENU BUTTON
Used to select the item.
SELECT BUTTON
Used to move the
Pointer UP/DOWN/
RIGHT/LEFT.
POINT BUTTONS
REMOTE CONTROL
MENU BUTTON
To Next Page
