Sanyo PLC-XP57L User Manual

5
TABLE OF CONTENTS
NAME OF EACH PART OF PROJECTOR 7
SETTING-UP PROJECTOR 8
CONNECTING AC POWER CORD 8
LENS INSTALLATION 9
ADJUSTABLE FEET 10
INSTALLING PROJECTOR IN PROPER POSITION 10
MOVING PROJECTOR 11
TERMINALS OF PROJECTOR 12
CONNECTING TO COMPUTERS 13
CONNECTING TO VIDEO EQUIPMENT 14
REMOTE CONTROL OPERATION 15
LASER POINTER FUNCTION 15
REMOTE CONTROL BATTERIES INSTALLATION 16
TOP CONTROLS AND INDICATORS 17
ON-SCREEN MENU 18
HOW TO OPERATE ON-SCREEN MENU 18
FLOW OF ON-SCREEN MENU OPERATION 18
MENU BAR 19
TURNING ON/OFF PROJECTOR 20
TURNING ON THE PROJECTOR 20
TURNING OFF THE PROJECTOR 21
ADJUSTING SCREEN 22
ZOOM ADJUSTMENT 22
FOCUS ADJUSTMENT 22
LENS SHIFT ADJUSTMENT 22
KEYSTONE CORRECTION 22
PICTURE FREEZE FUNCTION 23
NO SHOW FUNCTION 23
P-TIMER FUNCTION 23
SOUND ADJUSTMENT 23
TRADEMARKS
● Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple Computer,Inc.
● IBM and PS/2 are trademarks or registered trademarks of International Business Machines, Inc.
● Windows and PowerPoint are registered trademarks of Microsoft Corporation.
● Each name of corporations or products in the owner's manual is a trademark or a registered trademark of its respective corporation.
SELECTING INPUT SOURCE 24
SELECTING COMPUTER SYSTEM 25
PC ADJUSTMENT 26
AUTO PC ADJUSTMENT 26
MANUAL PC ADJUSTMENT 27
PICTURE IMAGE SELECT 29
IMAGE LEVEL SELECT 29
PICTURE SCREEN ADJUSTMENT 30
PICTURE SCREEN SELECT 30
SELECTING INPUT SOURCE 31
SELECTING VIDEO SYSTEM 32
PICTURE IMAGE SELECT 33
IMAGE LEVEL SELECT 33
PICTURE SCREEN ADJUSTMENT 34
PICTURE SCREEN SELECT 34
SETTING MENU 38
WIRELESS MOUSE 45
MAINTENANCE 46
WARNING TEMP. INDICATOR 46
AIR FILTERS CARE AND CLEANING 47
CLEANING PROJECTION LENS 47
LAMP REPLACEMENT 48
LAMP REPLACE COUNTER 49
TROUBLESHOOTING 50
MENU TREE 52
COMPATIBLE COMPUTER SPECIFICATIONS 54
INDICATORS AND PROJECTOR CONDITION 55
TECHNICAL SPECIFICATIONS 57
CONFIGURATIONS OF TERMINALS 58
OPTIONAL PARTS 59
LENS REPLACEMENT 59
PJ LINK NOTICE 59
PIN CODE NUMBER MEMO 60
DIMENSIONS 61
PICTURE IMAGE ADJUSTMENTS 35
FEATURES AND DESIGN 6
PREPARATION 7
CONNECTING PROJECTOR 12
BEFORE OPERATION 15
BASIC OPERATION 20
COMPUTER INPUT 24
VIDEO INPUT 31
PICTURE IMAGE 35
SETTING 38
APPENDIX 45

Sanyo PLC-XP57L Specifications

General

Number of colors	1.073 billion colors
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Resolution	2359296 pixels
Aspect ratio	4:3
Dimensions (WxDxH)	319 x 429.5 x 168 mm
Power requirements	100-240 V AC, 50/60 Hz
Lamp type	UHP
Lamp power	318 W
Light source type	Lamp
Noise level	36 dB
Dot clock scanning frequency	180 MHz
Analog signal format system	NTSC, NTSC 4.43, PAL, SECAM
Audio (L/R) in	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
VGA (D-Sub) ports quantity	5
Component video (YPbPr/YCbCr) in	3
Power consumption (standby)	15 W
Power consumption (typical)	480 W

Weight and Dimensions

Weight	7900 g
