BEFORE OPERATION
TOP CONTROLS AND INDICATORS
Used to open or
close the On-Screen
Menu. (pp.18, 19)
MENU BUTTON
IMAGE BUTTON
READY INDICATOR
SELECT BUTTON
POWER ON–OFF BUTTON
INPUT BUTTON
WARNING TEMP. INDICATOR
LAMP INDICATOR
POINT (VOLUME + / – ) BUTTONS
LAMP REPLACE INDICATOR
Used to select the
image level.
(pp.29, 33)
Lights green when the
projector is ready to be
turned on. And it blinks
green in the Power
management mode.
(pp.40, 46, 55–56)
Becomes dim when the
projector is turned on.
And it becomes bright
when the projector is in
stand-by mode.
(pp.20, 21, 55-56)
Turns to yellow when the
projection lamp reaches its
end of life.
Blinks yellow when the lamp
cannot light up.
(pp.48, 55–56)
Blinks red when the internal
temperature of the projector
is too high. (pp.46, 55–56)
Used to select an input
source. (pp.24, 31)
Used to select an item or adjust a
value in On-Screen Menu. They are
also used to pan the image in the
DIGITAL ZOOM +/– mode. (p.30)
The POINT LEFT/RIGHT buttons are
also used as VOLUME +/– buttons.
(p.23)
Used to execute the
selected item. It is also
used to expand/compress
the image in the DIGITAL
ZOOM mode. (p.30)
Used to turn the projector
on or off. (pp.20, 21)
Used to adjust zoom.
(p.22)
FOCUS BUTTON
Used to adjust focus.
(p.22)
ZOOM BUTTON
This projector has CONTROL BUTTONS (TOP CONTROLS) and INDICATORS on its top.
LENS SHIFT BUTTON
Used to select the Lens
Shift function. (p.22)
AUTO PC ADJ. BUTTON
Used to operate the Auto
PC Adjustment function.
(p.26)
