Sanyo PLC-XP57L User Manual

33
VIDEO INPUT
PICTURE IMAGE SELECT
Press the MENU button to display the On-Screen Menu.
Press the POINT LEFT/RIGHT buttons to move the red frame
pointer to the IMAGE SELECT Menu icon.
1
2
Press the POINT UP/DOWN buttons to move the red frame
pointer to the desired level and then press the SELECT
button.
IMAGE SELECT MENU
IMAGE LEVEL SELECT
Select an image level from among Standard, Cinema, Image
1 to Image 10 by pressing the IMAGE button on the top
control or on the remote control.
Move the red frame pointer to a level and
press the SELECT button.
IMAGE SELECT Menu icon
Normal picture level preset on this projector.
Picture level adjusted for picture with fine tone.
User preset picture adjustment in the IMAGE ADJUST Menu.
(pp.35–37)
Standard
Cinema
IMAGE 1–10
IMAGE button
Standard
Cinema
Image 1
Image 10
Normal picture level preset on this projector.
Standard
Picture level adjusted for picture with fine tone.
Cinema
User preset picture adjustment in the IMAGE ADJUST Menu.
(pp.35–37)
IMAGE 1–10
DIRECT OPERATION
MENU OPERATION

Sanyo PLC-XP57L Specifications

General

Number of colors	1.073 billion colors
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Resolution	2359296 pixels
Aspect ratio	4:3
Dimensions (WxDxH)	319 x 429.5 x 168 mm
Power requirements	100-240 V AC, 50/60 Hz
Lamp type	UHP
Lamp power	318 W
Light source type	Lamp
Noise level	36 dB
Dot clock scanning frequency	180 MHz
Analog signal format system	NTSC, NTSC 4.43, PAL, SECAM
Audio (L/R) in	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
VGA (D-Sub) ports quantity	5
Component video (YPbPr/YCbCr) in	3
Power consumption (standby)	15 W
Power consumption (typical)	480 W

Weight and Dimensions

Weight	7900 g
