28
COMPUTER INPUT
Exit the PC ADJUST Menu.
To store the adjusted parameters, move the red frame pointer to
the Store icon and then press the SELECT button. Move the red
arrow pointer to any of the Mode 1 to 10 in which you want to
store the parameters and then press the SELECT button.
To reset the adjusted parameters, select Reset and press the
SELECT button. A confirmation box appears. Select [Yes]. All
the adjustments return to their previous figures.
To store adjustment data.
To clear adjustment data.
To clear adjusted parameters previously set, move the red frame
pointer to the Mode free icon and then press the SELECT
button. Move the red arrow pointer to a Mode that you want to
clear and then press the SELECT button.
Reset
Mode free
Store
Quit
This Mode has parameters being stored.
Vacant
Shows the values of “Total
dots,” “Position H,” “Position V,”
“Display area H,” and “Display
area V.”
Close this dialog box.
Close this dialog box.
A confirmation box appears
and then select [Yes].
A confirmation box appears
and then select [Yes].

Sanyo PLC-XP57L Specifications

General

Number of colors	1.073 billion colors
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Resolution	2359296 pixels
Aspect ratio	4:3
Dimensions (WxDxH)	319 x 429.5 x 168 mm
Power requirements	100-240 V AC, 50/60 Hz
Lamp type	UHP
Lamp power	318 W
Light source type	Lamp
Noise level	36 dB
Dot clock scanning frequency	180 MHz
Analog signal format system	NTSC, NTSC 4.43, PAL, SECAM
Audio (L/R) in	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
VGA (D-Sub) ports quantity	5
Component video (YPbPr/YCbCr) in	3
Power consumption (standby)	15 W
Power consumption (typical)	480 W

Weight and Dimensions

Weight	7900 g
