MZ7-XT2500, MZ7-XT25L00, KC6-XT2000, KC6-XT20L00
Electrical Parts List
-108-
Electrical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Key No. Part No. Description Key No. Part No. Description
ASSEMBLIED BOARDS
For CHASSIS No. MZ7-XT2500, MZ7-XT25L00
! 910 330 0116 ASSY,PWB,MAIN .MZ7A
! 910 330 5067 ASSY,PWB,AV MZ7A
! 910 330 5159 ASSY,PWB,NETWORK JOINT MZ
! 910 330 5166 ASSY,PWB,R/C. FRONT MZ7A
For CHASSIS No. KC6-XT2000, KC6-XT20L00
! 610 333 2482 ASSY,PWB,MAIN .KC6A
! 910 330 5067 ASSY,PWB,AV MZ7A
! 910 330 5159 ASSY,PWB,NETWORK JOINT MZ
! 910 330 5166 ASSY,PWB,R/C. FRONT MZ7A
OUT OF CIRCUIT BAORD
L901 945 003 3835 CORE,FERRITE
L902 945 003 3811 CORE,FERRITE
LP901 610 330 7329 COMPL,OPTICAL LMP-MZ7A
! A901 945 085 8278 UNIT,BALLAST
! A902 945 087 1611 UNIT,POWER(AC)
! A903 945 087 1628 UNIT,POWER(DC)
! A904 945 087 1635 UNIT,POWER(FILTER)
BLST&LMP 910 330 7474 CABLE,BALLAST MZ7A
! FN901 945 088 7049 MOTOR,FAN DC 3.36W
! FN902 945 088 7063 MOTOR,FAN DC 4.20W
! FN903 945 088 7025 MOTOR,BLW DC 1.92W
! FN904 945 088 7032 MOTOR,BLW DC 9.24W
! FN905 645 091 1439 MOTOR,BLW DC 9.24W
SP901 945 078 6106 SPEAKER,8
! SW901 645 089 4879 THERMOSTATS
SW902 645 089 4916 SWITCH,PUSH
TH901 945 079 7775 SWITCH,THERMAL,THERMISTOR
TH902 945 079 7768 SWITCH,THERMAL,THERMISTOR
! FUSE 645 090 3144 FUSE(250V,10A)
For CHASSIS No. MZ7-XT2500, MZ7-XT25L00
910 330 0116 ASSY,PWB,MAIN .MZ7A
For CHASSIS No. KC6-XT2000, KC6-XT20L00
610 333 2482 ASSY,PWB,MAIN .KC6A
TRANSISTOR
Q1011 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1061 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q156 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q158 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q161 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q166 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q171 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 002 0311 TR 2SA1037K T146 R
305 002 0410 TR 2SA1037K T146 S
305 002 6729 TR 2SA1179-M6-TB
305 002 6927 TR 2SA1179-M7-TB
305 163 1516 TR 2SA1179N-M6-TB
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Q176 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q181 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q182 305 014 4512 TR 2SC2412K T146 R
To Next Page
