 ●: Adjustment necessary ❍: Check necessary
Adjustments after Parts Replacement
Adjustments
Disassembly / Replaced Parts
LCD/
Prism
Ass’y
Conden-
sor
Lens
Relay
Lens
(OUT)
Polarized
Glass
(POL)
Optical
Filter
(WV)
Integ-
rator
Lens
PBS
Power
Board
Main
Board
Fans
Optical
Adjustment
Optical axies adjustment
● ● ● ● ●
Contrast adjustment (POL)
● ●
Contrast adjustment (WV)
● ●
Electrical Adjustments
Fan control adjustment
● ● ●
Panel type check and setting
● ●
PC-Auto calibration adjustment
●
Video-Auto calibration adjustment
●
480i-Auto calibration adjustment
●
Common center adjustment
❍ ●
50% luminance adjustment [PC]
●
50% luminance adjustment [Video]
●
White balance adjustment [PC]
❍ ●
White balance adjustment [Video]
❍ ●
White uniformity adjustment
❍ ❍
Filter calibration adjustment
● ● ●

Sanyo PLC-XT25 Specifications

General

Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Resolution	1024 x 768 pixels
Dimensions (WxDxH)	302 x 422 x 162 mm
Display diagonal	1 \
Lamp type	UHP
Lamp power	300 W
Light source type	Lamp
Market positioning	Portable

Weight and Dimensions

Weight	9200 g
