-92-
Chassis Description
Error Error Code
Error Infomation
(See Powe Failure Detection Tree)
Normal 0 -
Power Failure
1000 MAIN, 1,8/1.2V
1001 MAIN, S-5V
1002 FPGA, S1.2
1003 MAIN, 15/9/5V
1004 MAIN, S5/S9/S12V
1005 PJ_N/AV, 3.3/S5V
1006 FAN1, FANLOCK
1007 FAN2, FANLOCK
1008 FAN3, FANLOCK
1009 FAN4, FANLOCK
1010 FAN5, FANLOCK
1011 FPGA, CONFIG
Temperature Error
2000 Sensor A detects abnormal temperature.
2001 Sensor A fails measurement.
2100 Sensor B detects abnormal temperature.
2101 Sensor B fails measurement.
2102 Sensors B-A temperature error.
2200 Sensor C detects abnormal temperature.
2201 Sensor C fails measurement.
2202 Sensors C-A temperature error.
Lamp Error
3000 Lamp1 fails on
3001 Lamp1 goes out
3002 Communication Error on Lamp1
Filter Error
4000 Air Filter Clogged
Error History Log
This projector provides the error history log function. To check the logs, you need to enter the service mode and select
Group No. "220" and Item No. "0" to "49". The error code is displayed on the Data column. The description of the error
code is listed on the table below.
* How to enter the service mode and select the group, item and data value, see "Service Adjustment Menu Opera-
tion".
Group No. Item No. Data (Error Code) (See table below)
220 0
] <- Latest Error
1 ]
2
]
3 ]
. ]
. ]
. ]
48 ]
49 ]
How to clear the Error History Log
1. Enter the Service Mode, and select Group No. "220" and Item No. "50".
2 The history log will be claered when the Data Value is set to "10". The value automatically returns to "0".
* How to enter the service mode and select the group, item and data value, see "Service Adjustment Menu Operation".
