Sanyo PLC-XT25 User Manual

-81-
Chassis Description
INPUT1 INPUT2 INPUT3
IC5001
AUDIO-SW
<NJW1141>
AV JOINT
MAIN
IC1371
BUS-SW
SPEAKER
SP901
L,R L,R L,R
1,30
10 21 13 14
4 1
2,29 3,28
AUDIO
OUT
L,R 9,22
3 5
26
Q5031
K40E K30A
Q5032
Q5041/Q5042
Q5151
Q5141
Q5042 Q5047
IC5121
AUDIO
OUT
<LM4889>
1 3
K8H
IC301
SCAN
CONVERTER
&
SYSTEM
CONTROL
<PW190>
SCL0_S5V
AUDIO_OUT_DET
SDA0_S5V
SCL0_S5V
SDA0_S5V
293 212 101
AUDIO
ADUIO_MUTE
MUTE
Mute On: H
13 14 23 24 21 22 15 16 17 18
K30B K8S
107 108
97 98 99
100 105 106 103 104
Audio signal processing stage

Sanyo PLC-XT25 Specifications

General

Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Resolution	1024 x 768 pixels
Dimensions (WxDxH)	302 x 422 x 162 mm
Display diagonal	1 \
Lamp type	UHP
Lamp power	300 W
Light source type	Lamp
Market positioning	Portable

Weight and Dimensions

Weight	9200 g
