-64-
Electrical Adjustment
Service Adjustment Data Table
These initial values are the reference data written from the
CPU ROM to memory IC when replaced new memory IC. The
adjustment items indicated with “✻” are required to readjust fol-
lowing to the “Electrical adjustments”. Other items should be
used with the initial data value.
Group/
Item
Item Name Function Initial Range Note
Group 0 AD Converter (PW190)
0 ADC G-OFFSET PC / Component / SCART 128/120/128 0 - 255 * G-Pedestal Adjustment [480i]
1 ADC R-OFFSET PC / Component / SCART 128/140/128 0 - 255 * R-Pedestal Adjustment [480i]
2 ADC B-OFFSET PC / Component / SCART 128/140/128 0 - 255 * B-Pedestal Adjustment [480i]
3 ADC G-GAIN PC / Component / SCART 50/50/50 0 - 255 * Gain Adjustment [480i]
4 ADC R-GAIN PC / Component / SCART 40/40/40 0 - 255
5 ADC B-GAIN PC / Component / SCART 40/40/40 0 - 255
6 GRAAFLTR/RBAAFLTR Green (Red and Blue) Anti-Alias Filter 4 / R / R 0 - 7
7
GRNAADWNSMPL / RBAAD-
WNSMPL
Green (Red and Blue) Anti-Alias Downs-
ample
0 / R / R 0 - 3 Composite & S-Video / Component / PC
8 GRNAAHF / RBAAHF
Green (Red and Blue) Anti-Alias High
Frequency
3 / R / R 0 - 3 *R: Read only value
10 SOGTH
PC / Component / SCART
SyncOn Green Threhould
4 / 3 / 2 0 - 15
11 SOGHYSDIS
PC / Component / SCART
Sync On Green Hsysterisis Enable
0 0 - 1
12 HS1TH 4 0 - 7
13 HS0TH 4 0 - 7
100 PreCoast PC Signal 3 0 - 63
101 PostCoast PC Signal 8 1 - 63
120 PreCoast PC Video 480i 7 0 - 63
121 PostCoast PC Video 480i 13 0 - 63
122 PreCoast PC Video 575i 7 0 - 63
123 PostCoast PC Video 575i 13 0 - 63
124 PreCoast PC Video 480p 7 0 - 63
125 PostCoast PC Video 480p 13 0 - 63
126 PreCoast PC Video 575p 7 0 - 63
127 PostCoast PC Video 575p 13 0 - 63
128 PreCoast PC Video 720p 60Hz 7 0 - 63
129 PostCoast PC Video 720p 60Hz 13 0 - 63
130 PreCoast PC Video 720p 50Hz 7 0 - 63
131 PostCoast PC Video 720p 50Hz 13 0 - 63
132 PreCoast PC Video 1080i 60Hz 7 0 - 63
133 PostCoast PC Video 1080i 60Hz 13 0 - 63
134 PreCoast PC Video 1080i 50Hz 7 0 - 63
135 PostCoast PC Video 1080i 50Hz 13 0 - 63
136 PreCoast PC Video 1035i 7 0 - 63
137 PostCoast PC Video 1035i 13 0 - 63
150 PreCoast YCbCr 480i 7 0 - 63
151 PostCoast YCbCr 480i 13 0 - 63
152 PreCoast YCbCr 575i 7 0 - 63
153 PostCoast YCbCr 575i 13 0 - 63
154 PreCoast YCbCr 480p 7 0 - 63
155 PostCoast YCbCr 480p 13 0 - 63
156 PreCoast YCbCr 575p 7 0 - 63
157 PostCoast YCbCr 575p 13 0 - 63
158 PreCoast YCbCr 720p 60Hz 7 0 - 63
159 PostCoast YCbCr 720p 60Hz 13 0 - 63
160 PreCoast YCbCr 720p 50Hz 7 0 - 63
161 PostCoast YCbCr 720p 50Hz 13 0 - 63
162 PreCoast YCbCr 1080i 60Hz 7 0 - 63
163 PostCoast YCbCr 1080i 60Hz 13 0 - 63
164 PreCoast YCbCr 1080i 50Hz 7 0 - 63
165 PostCoast YCbCr 1080i 50Hz 13 0 - 63
166 PreCoast YCbCr 1035i 7 0 - 63
167 PostCoast YCbCr 1035i 13 0 - 63
180 PreCoast SCART 480i 7 0 - 63
181 PostCoast SCART 480i 13 0 - 63
182 PreCoast SCART 575i 7 0 - 63
