MZ7-XT2500, MZ7-XT25L00, KC6-XT2000, KC6-XT20L00
-135-
Mechanical Parts List
CABINET PARTS
C01 910 330 7566 ASSY,STAND LEG-MZ7A
C02 910 330 7269 BUTTON CTRL-MZ7A
C03 910 330 7559 BUTTON LNS A-MZ7A
C04 910 330 7535 BUTTON LNS B-MZ7A
C05 910 330 7306 CABINET TOP-MZ7A
C06 910 330 7245 CABINET BOTTOM-MZ7A
C07 910 301 4990 CAP LNS-MC3A
C08 910 330 7238 COVER LNS TOP-MZ7A
C09 910 330 7399 COVER LNS BTM-MZ7A
C10 910 330 7573 DEC LED-MZ7A
C11 910 295 3085 DEC LEG-MW6A
C12 910 302 5613 DEC SHEET-M4JA
C13 910 330 7443 DEC AV SHEET-MZ7A
C14 910 330 7184 FILTER BASE-MZ7A
C15 910 323 6767 HOLDER SPEAKER-MT5A
C16 910 330 7191 PANEL AV-MZ7A
C17 910 330 7368 PANEL LMP-MZ7A
C18 910 330 7412 PANEL FILTER-MZ7A
C19 910 330 7405 PANEL PRM-MZ7A
C20 910 330 7542 PANEL PJNET-MZ7A
C21 910 297 7920 SPACER COVER NWMG-MA8AA
C22 910 297 7937 SPACER COVER SCREW NWMG-MA8AA
C23 910 330 7436 SPRING BUTTON LNS-MZ7A
CHASSIS PARTS
M01 910 330 8334 COMPL,MOUNTING LNS-MZ7A
(Including Key No. M01-1 to M01-3)
M01-1 945 088 7681 ASSY,MOTOR LENS MZ7A
M01-2 645 089 4886 UNIT,LENS,SHIFT-X
M01-3 645 089 4893 UNIT,LENS,SHIFT-Y
M02 910 330 7917 COVER DUCT PANEL TOP-MZ7A
M03 910 330 8129 COVER DUCT PANEL IN-MZ7A
M04 910 330 8204 HOLDER POL IN-MZ7A
M05 910 330 7795 HOLDER WV IN-MZ7A
M06 910 330 7764 HOLDER CON BALLAST-MZ7A
M07 910 330 8075 MOUNTING LNS CON A-MZ7A
M08 910 330 7740 MOUNTING LNS REL A-MZ7A
M09 610 331 9070 STOPPER THERM POL IN-MZ7A
M10 910 330 8082 OPTICAL BASE TOP-MZ7A
M11 910 330 8310 OPTICAL BASE BTM-MZ7A
SCREWS
S01 411 031 9304 SCR BIN 3X8
S02 312 069 7402 SPECIAL SCREW NI
S03 411 189 6507 BOLT HEX-SCT+SW+W 2.5X5
S04 411 189 6606 BOLT HEX-SCT 2.5X6
OPTICAL PARTS
For CHASSIS NO. MZ7-XT2500, KC6-XT2000
L01 645 090 0617 ASSY,LENS,PROJECTION
(Includding Key No. L011-1 to L01-3)
L01-1 945 057 8497 MOTOR,LENS(F-UNIT)
L01-2 945 057 8503 MOTOR,LENS(Z-UNIT)
L01-3 945 055 5351 LENS,PROJECTION-LM
For CHASSIS NO. MZ7-XT2500, MZ7-XT25L00
L02 (Including Key No. L02-1 to L02-4 and LCD panels)
Type-L LCD Panel/Prism Ass'y
610 333 1867 ASSY,LCD PNL/PRISM RLR-MZ7A
Type-R LCD Panel/Prism Ass'y
610 333 1850 ASSY,LCD PNL/PRISM LRL-MZ7A
L02-1 945 088 7568 POLARIZED GLASS(OUT/R)
L02-2 945 088 7575 POLARIZED GLASS(OUT/G)
L02-3 645 090 1942 POLARIZED GLASS(OUT/B)
L02-4 645 090 2307 PREPOLARIZED GLASS(OUT)
Parts for Type-L LCD Panel/Prism Ass'y
L03 645 090 2680 OPTICAL FILTER (HCP)R
L04 645 090 2697 OPTICAL FILTER (HCP)L
L05 645 090 2680 OPTICAL FILTER (HCP)R
Parts for Type-R LCD Panel/Prism Ass'y
L03 645 090 2697 OPTICAL FILTER (HCP)L
L04 645 090 2680 OPTICAL FILTER (HCP)R
L05 645 090 2697 OPTICAL FILTER (HCP)L
L15 945 088 7322 LENS,CONDENSER(OUT)
For CHASSIS NO. KC6-XT2000, KC6-XT20L00
L02 (Including Key No. L02-1 to L02-4 and LCD panels)
Type-L LCD Panel/Prism Ass'y
610 333 1980 ASSY,LCD PNL/PRISM RLR-KC6A
Type-R LCD Panel/Prism Ass'y
610 333 1874 ASSY,LCD PNL/PRISM LRL-KC6A
L02-1 945 088 7568 POLARIZED GLASS(OUT/R)
L02-2 945 088 7575 POLARIZED GLASS(OUT/G)
L02-3 645 090 1942 POLARIZED GLASS(OUT/B)
L02-4 645 090 2307 PREPOLARIZED GLASS(OUT)
Parts for Type-L LCD Panel/Prism Ass'y
L03 645 090 2680 OPTICAL FILTER (HCP)R
L04 645 090 2697 OPTICAL FILTER (HCP)L
L05 645 090 2680 OPTICAL FILTER (HCP)R
Parts for Type-R LCD Panel/Prism Ass'y
L03 645 090 2697 OPTICAL FILTER (HCP)L
L04 645 090 2680 OPTICAL FILTER (HCP)R
L05 645 090 2697 OPTICAL FILTER (HCP)L
L15 645 091 6007 LENS,CONDENSER(OUT)
Common Parts
L06 945 088 7520 PREPOLARIZED GLASS(IN)
L07 945 088 7537 POLARIZED GLASS(IN/R)
L08 945 088 7544 POLARIZED GLASS(IN/G)
L09 645 090 1935 POLARIZED GLASS(IN/B)
L10 945 088 7223 ASSY,PRISM(PBS)
L11 645 090 0600 LENS,PROJECTION-SM
L12 945 088 7254 LENS,INTEGRATOR(IN)
L13 645 091 5260 LENS,INTEGRATOR(OUT)
L14 945 088 7315 LENS,CONDENSER(IN)
L16 645 091 5284 LENS,CONDENSER(G)
L17 945 088 7346 LENS,CONDENSER(B)
L18 945 088 7353 LENS,RELAY(IN)
L19 945 088 7360 LENS,RELAY(OUT)
L20 945 088 7377 LENS,CONDENSER(R)
L21 945 088 7384 MIRROR(W-COLD)
L22 945 088 7391 MIRROR(B)
L23 945 088 7407 MIRROR(R)
L24 945 055 5405 DICHROIC MIRROR (G)
L25 945 055 5412 DICHROIC MIRROR (B)
* There are 2 types (Type-L or Type-R) of LCD Panel/Prism Ass'y. Used type
is indicatyed on the Prism Ass's and Cabinet top. Refter to item "LCD
Panel/Prism Ass'y Removal" for further information.
Key No. Part No. Description
Key No. Part No. Description
Mechanical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
