Sanyo PLC-XU106 User Manual

22
How to Operate the On-Screen Menu
The projector can be adjusted or set via the On-Screen
Menu. The menus have a hierarchical structure, with
a main menu that is divided into submenus, which are
further divided into other submenus. For each adjustment
and setting procedure, refer to respective sections in this
manual.
Use the Point
Ÿź buttons to highlight and select a
main menu item. Press the Point
Ź or the SELECT
button to access the submenu items. (The selected
item is highlighted in ORANGE.)
Use the Point
Ÿź buttons to select the desired
submenu item and press the SELECT button to set or
access the selected item.
Press the MENU button on the top control or the
remote control to display the On-Screen Menu.
1
2
3
On-Screen Menu
Top Control
MENU button
POINT buttons
(arrowhead)
Remote Control
SELECT button
MENU button
SELECT button
POINT buttons
(arrowhead)
Point
Ź or SELECT
button
Use the Point ŸźŻŹbuttons to adjust the setting or
switch between each option and press the SELECT
button to activate it and return to the submenu.
4
Press the Point Ż button to return to the main menu.
Press the MENU button to exit the On-Screen Menu.
5
The currently set item is
check marked.
The selected item is
highlighted in ORANGE.
Basic Operation

Sanyo PLC-XU106 Specifications

General

Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	275 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3000 h
Focus	Manual
S-Video inputs quantity	1
Dimensions (WxDxH)	335.7 x 93.9 x 257.5 mm
Noise level	37 dB
Power consumption (standby)	0.9 W
Power consumption (typical)	332 W

Weight and Dimensions

Weight	3400 g
