Sanyo PLC-XU106 User Manual

7
Use the projector properly in specified positions. Improper positioning may reduce the lamp life and result in severe
accident or fire hazard.
This projector can project the picture upward, downward, or backward, perpendicular to the plane of the screen as
shown in the figure below.
Bottom
Downward
(Usual)
Front
Downward
Bottom
Upward
Front
Upward
Installing the Projector in Proper Directions
Avoid positioning the projector as described below when installing.
Positioning Precautions
Do not roll the projector more than 10 degrees from side to side.
Do not put the projector on either side to project an image.
Û
Û
10Û0
Û
10
Û
10
Û
In upward projection, do not tilt the projector over 10 degrees right and left.
In downward projection, do not tilt the projector over 10 degrees right and left.
Safety Instructions
0º
90º
180 º
40º
50º
140º
50º
40º
Be sure to set the Lamp control in High and the Fan
control in On 3 in the setting Menu when using the
projector inclined at between +40 degrees to +140
degrees to the horizontal plane at altitudes between
0 and approximately 1,600 meters above sea level.
Be sure to set the Fan control in On 2 when using
the projector at higher altitudes than the altitudes
described above, regardless of the installation
position of the projector. (p.57)

Sanyo PLC-XU106 Specifications

General

Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	275 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3000 h
Focus	Manual
S-Video inputs quantity	1
Dimensions (WxDxH)	335.7 x 93.9 x 257.5 mm
Noise level	37 dB
Power consumption (standby)	0.9 W
Power consumption (typical)	332 W

Weight and Dimensions

Weight	3400 g
