Sanyo PLC-XU106 User Manual

76
COMPUTER IN 1 /COMPONENT IN /COMPUTER IN 2/MONITOR OUT (ANALOG)
Terminal: Analog RGB (Mini D-sub 15 pin)
5
1
2
34
10
9 678
15
14
13
1112
Configurations of Terminals
Red (R/Cr) Input/Output
Ground (Horiz.sync.)
Green (G/Y) Input/Output
-----
Blue (B/Cb) Input/Output
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
+5V Power/-----
Horiz. sync. Input/Output (Composite H/V sync.)
Ground (Vert.sync.)
DDC Data
/-----
Ground/-----
Vert. sync.
DDC Clock
/-----
9
13
10
12
11
14
15
RX –
TX +
TX –
RX +
2
3
4
87654321
5
6
7
8
1
LAN TERMINAL
-----
-----
----------
CONTROL PORT CONNECTOR (D-sub 9 pin)
-----
RXD
TXD
-----
SG
-----
RTS
CTS
Serial
1
2
3
4
5
6
7
8
-----9
Appendix

Sanyo PLC-XU106 Specifications

General

Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	275 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3000 h
Focus	Manual
S-Video inputs quantity	1
Dimensions (WxDxH)	335.7 x 93.9 x 257.5 mm
Noise level	37 dB
Power consumption (standby)	0.9 W
Power consumption (typical)	332 W

Weight and Dimensions

Weight	3400 g
