Part Names and Functions
Adjustable Feet
Toensuresafeoperation,pleaseobservethefollowingprecautions:
 ● Usetwo(2)AAAorLR03typealkalinebatteries.
 ● Alwaysreplacebatteriesinsets.
 ● Donotuseanewbatterywithausedbattery.
 ● Avoidcontactwithwaterorliquid.
 ● Donotexposetheremotecontroltomoistureorheat.
 ● Donotdroptheremotecontrol.
 ● Ifthebatteryhasleakedontheremotecontrol,carefullywipethecasecleanandinstallnewbatteries.
 ● Riskofanexplosionifbatteryisreplacedbyanincorrecttype.
 ● Disposeofusedbatteriesaccordingtotheinstructions.
Pressthelid
downwardandslideit.
Openthebattery
compartmentlid.
Installnewbatteries
intothecompartment.
Replacethe
compartmentlid.
Two AAA size
batteries
Forcorrectpolarity
(+and–),besure
batteryterminalsare
incontactwithpinsin
compartment.
1 2 3
Point the remote control toward the projector (Infrared
Remote Receiver) when pressing the buttons. Maximum
operating range for the remote control is about 16.4'(5 m)
and60degreesinfrontoftheprojector.
Remote Control Operating Range
Remote Control Battery Installation
Projectionanglecanbeadjustedupto8.9degreeswiththe
adjustablefeet.
Liftthefrontoftheprojectorandpullthefeetlocklatcheson
bothsideoftheprojectorupward.
Releasethefeetlocklatchestolocktheadjustablefeetand
rotatetheadjustablefeettoaproperheight,andtilt.
Keystone distortion can be adjusted automatically with the
Autosetupfunctionormanuallybyusingtheremotecontrol
orthemenuoperation(seepages26,47-48).
AdjustableFeet FeetLockLatches
16.4'
(5m)
30°
Remotecontrol
30°
