Sanyo PLC XU115 - XGA LCD Projector

33
Computer Input
AutoPCAdjustmentfunctionisprovidedtoautomaticallyadjustFinesync,Totaldots,HorizontalandVertical
positionstoconformtoyourcomputer.
Movetheredframepointer
toAutoPCAdj.andpress
theSELECTbutton.
“Pleasewait...”appears
whiletheAutoPC
adjustmentisinprocess.
PC Adjust Menu
PCAdjustMenuicon
Auto PC Adjustment
Remote Control
AUTO PC button
TheAuto PC adjustment function can be operated directly
bypressingtheAUTOPCbuttonontheremotecontrol.
Direct Operation
To store adjustment parameters
TheadjustedparametersfromtheAutoPCAdjustmentcan
bestoredintheprojector.Oncetheparametersarestored,
thesettingcanbedonejustbyselectingaMode(1–5)inthe
PCSystemMenu(p.32).Seealso“Store”onpage35.
Notes:
 •Finesync,Totaldots,HorizontalandVerticalpositionof
somecomputerscannotbe fullyadjustedwiththeAuto
PCAdjustmentfunction.Whentheimageisnotprovided
properly with this operation, manual adjustments are
required(pp.34–35).
 •TheAutoPCAdjustmentcannotbeoperatedwhen480i,
575i,480p,575p,720p,1035i,or1080iisselectedinthe
PC System Menu (p.32), or when the signal is coming
fromtheDVI-terminal.
PresstheMENUbuttontodisplaytheOn-Screen
Menu.UsethePoint◄►buttonstomovethered
framepointertothePCAdjustMenuicon.
1
2
UsethePoint▲▼buttonstomovetheredframe
pointertoAutoPCAdj.andthenpresstheSELECT
buttontwice.
Auto PC Adj.
Menu Operation
