Installation
Connecting to a Computer
SD
KB3AC
Cables used for connection
•VGACable(MiniD-sub15pin)*
•DVI-VGACable
•DVICable
•USBCable
•AudioCables
(*Onecableissupplied;othercablesarenotsuppliedwiththeprojector.)
ExternalAudioEquipment
DVI-VGA
cable
USBcable
Audiocable
(stereo)
USBportAudioOutput
USB
COMPUTER/
COMPONENT
AUDIOIN
AUDIOOUT
(stereo)
AudioInput
COMPUTERIN1
DVI-I
Notes:
•Input sound to the COMPUTER/COMPONENTAUDIOIN
terminal when using the COMPUTER IN 1/DVI-I and the
COMPUTERIN2/COMPONENTINterminalasinput.
 •When theAUDIO OUT is plugged-in, the projector's built-in
speakerisnotavailable.
 •USBcableconnectionisneededwhenoperatingthecomputer
withtheremotecontrolorusingthePAGE▲▼buttonsonthe
remotecontrol.
Monitor
Output
COMPUTERIN2/
COMPONENT
VGAcable
MONITOR
OUT
Audiocable
(stereo)
Unplug the power cords of both the
projector and external equipment
fromtheAC outlet before connecting
cables.
VGAcable
Monitor
Output
Monitor
Input
DVI
cable
Monitor
Output
