Sanyo PLC XU115 - XGA LCD Projector User Manual

35
Computer Input
Vacant
Values of “Total dots”,
“Horizontal”,“Vertical”,
“Display area H”, and
“DisplayareaV”.
Closethisdialogbox.
To store adjusted data
To clear adjusted data
ThisModehasstored
parameters.
Movetheredframepointer
to the desired item and
presstheSELECTbutton.
UsethePoint◄►buttonstoadjustthehorizontalarea
displayedbythisprojector.
Display area H
UsethePoint◄►buttonstoadjusttheverticalareadisplayed
bythisprojector.
Display area V
Reset
Store
ExitthePCAdjustMenu.
Quit
Tostoretheadjusteddata,selectStoreandthenpressthe
SELECT button. Move the red arrow pointer to one of the
Modes1to5inwhichyouwanttostore,andthenpressthe
SELECTbutton.
To reset the adjusted data, select Reset and press the
SELECTbutton.Aconfirmationboxappearsandthenselect
[Yes].Alladjustmentswillreturntotheirpreviousfigures.
Mode free
To clear the stored data, select Mode free and then press
theSELECTbutton.MovetheredarrowpointertotheMode
thatyouwanttoclearandthenpresstheSELECTbutton.
Notes:
 •Displayarea (H/V) cannotbe selectedwhen 480i, 575i,
480p,575p,720p,1035i,or1080iisselected inthePC
SystemMenu(p.32).
 •PC Adjust Menu cannot be selected when Computer
1(Digital)isselectedintheInputMenu(p.31).
