Sanyo PLC-XU4000 - Image Adjustment

42
Image Adjustment
1
2
Press the Point ◄ button to decrease the contrast; press the
Point ► button to increase the contrast (from 0 to 63).
Press the Point ◄ button to decrease the brightness; press
the Point ► button to increase the brightness (from 0 to 63).
Contrast
Brightness
Use the Point ◄► buttons to select the desired Color temp.
level (XLow, Low, Mid or High).
Color temp.
Press the Point ◄ button decrease the intensity of the color;
press the Point ►button increase the intensity of the color
(from 0 to 63).
Press the Point ◄► buttons to adjust the tint value to get a
proper color balance (from 0 to 63).
Color
Tint
Image adjust Menu
Press the MENU button to display the On-Screen
Menu. Use the Point ▲▼ buttons to select the Image
adjust and then press the Point ► or the SELECT
button.
Use the Point ▲▼ buttons to select the desired item
and then press the SELECT button to display the
adjustment dialog box. Use the Point ◄► buttons to
adjust the setting value.
Selected Image mode
Use the Point◄►buttons
to adjust the setting value.
 Note:
 •WhentheWhite balance Red, Green or Blue is adjusted, the Color temp. level will change to User.
 •Tint cannot be selected when the video system is PAL, SECAM, PAL-M or PAL-N (p.40).
 •WhenBlackboard(Green)orColorboardisselectedinImageselect,Color temp. will change to Blackboard
or Colorboard.
Video Input
Press the Point ◄ button to lighten R/G/B tone; press the
Point ► button to deepen R/G/B tone (from 0 to 63).
White balance (Red/Green/Blue)
