P1
105
o
C
Auto.
85
o
C 5.4min
HEATER TEST 160
o
C
S
37
Data Output
There are three options for data output:
– Output to the moisture analyzer
– Output to an external printer (YDP02-0CE or YDP03-0CE)
– Output to a peripheral device (e.g. a computer) via the interface port
Output to the Moisture Analyzer Display
(weights and calculated values)
The display is divided into 9 sections. Information on the weighing system,
the application being used and the sample weighed is output in the following sections:
– Info/drying program status/test function
– Print symbol
– Bar graph
– Busy symbol
– Plus/minus sign
– Measured value/result
– Unit
– Graphic symbol
– Function line
Info/Drying program status/Test function
This line shows information on the drying program:
– Program number
– Temperature data
– Shutoff parameter
– Current temperature and time
– Active test function with parameters
Print Symbol
The print symbol is displayed in this area: after pressing the r key or after start
and end of moisture measurement.
Bar Graph (Overview Display)
The bar graph shows the target weight with tolerances (–20%, +20%).
The bar graph is displayed if
ON is selected as the “Initial weight” parameter in
the drying program.
Unit
Graphic symbol
Print symbol
Info/Drying program status/Test function
Bar graph
Measured value/result
Function line
Plus/minus sign
Busy symbol
