Sartorius SIWABBP User Manual

Signum 1-2-3
Settings
33
Setup
uniCom1
3
printer Printer configuration
YDP01IS YDP01IS
line * Strip printer
label Label printer
lab ff Label printer with manual feed
YDP02 YDP02 variants
5.1. to 5.4.
Numeric menu similar to COM1
YDP03 YDP03-0CE, YDP20-0CE
5.1. to 5.4.
Numeric menu similar to COM1
YDP02IS YDP023IS
line * Strip printer
label Label printer
Uni-pri Universal interface
5.1. to 5.6.
Numeric menu similar to COM1
YDP04IS * YDP04IS
line * Strip printer
label Label printer
lab ff Label printer with manual feed
yam01is
3
) YAM01IS as electronic memory for print data
Analog Analog data output port for PLC operation
8.12. Analog output: value
8.12. * Net value
8.12.2 Gross value
8.13. Analog output: error indicator
8.13.1 * High level (20 mA)
8.13.2 Low level (0/4 mA). When menu is open or during calibration:
0/4 mA on this interface.
8.14. Analog output: mode
8.14.1 *
1
) Zero to maximum capacity
8.14.2 Min./max. values
8.15.
2
) Analog output: min./max.
8.15.1 Min. (0/4 mA) input in kg
8.15.2 Max. (20 mA) input in kg
8.16. Analog output: calibration values
8.16.1 4 mA measured value entry
8.16.2 20 mA measured value entry
Memory
3
) Verifiable data memory
yam01is YAM01IS external data memory
comspec
4
Optional:
Reference scale connection (option A15)
OFF
ADU configuration: see operating instructions
supplied with Option A15 for details)
1
) = When setting 8.14.1 is active, analog data output only works for XBPI weighing instruments
2
) = Not with setting 8.14.1
3
) = Only if no internal alibi memory is available

Sartorius SIWABBP Specifications

General

Brand	Sartorius
Model	SIWABBP
Category	Scales
Language	English
