Setup
ctrl io
5
External key
(Display designation of this menu level: 5 )
ctr inp Input ports
8. 4. Function for external key (universal)
8.4.1 * Trigger p key function
8 4.2 Trigger p “long" key function
8.4.3 Trigger ) key function
8.4.4 Trigger
J key function
8.4.5 Trigger k key function
8.4.6 Trigger n key function Signum
®
2 and 3 only
8.4.7 Trigger O key function Signum
®
2 and 3 only
8.4.8 Combined zero/tare function
8.4.9 Trigger ( key function
8.4.10 Trigger e key function
8.4.11 Trigger c key function Signum
®
2 and 3 only
8.4.12 Trigger
I key function Signum
®
2 and 3 only
8 4.13 Trigger D key function Signum
®
3 only
8.17. External input 1
8.17.1 Trigger p key function
’’ ’’
8.17.13 Trigger D key function Signum
®
3 only
8.18. External input 2
8.18.1 Trigger p key function
’’ ’’
8.18.13 Trigger D key function Signum
®
3 only
8.19. External input 3
8.19.1 Trigger p key function
’’ ’’
8.19.13 Trigger D key function Signum
®
3 only
8.20. External input 4
8.20.1 Trigger p key function
’’ ’’
8.20.13 Trigger D key function Signum
®
3 only
8.21. External input 5
8.21.1 Trigger p key function
’’ ’’
8.2.13 Trigger D key function Signum
®
3 only
ctr out External output ports
8. 24. External output 1
8.24.1 * Weighing instrument ready to operate
8.24.2 Weighing instrument stable
8.24.3 Weighing instrument overflow (“H”)
8.24.4 Weighing instrument underflow (“L”)
8.24.5 Value in tare memory
8.24.6 Below SQmin load
8.24.7 Above SQmin load
8.24.8 Lighter Signum
®
2 and 3 only
8.24.9 Equal Signum
®
2 and 3 only
8.24.10 Heavier Signum
®
2 and 3 only
8.24.11 Set Signum
®
2 and 3 only
8.25. External output 2
8.25.1 Weighing instrument ready to operate
’’ ’’
8.25.11 Set
8.26. External output 3
8.26.1 Weighing instrument ready to operate
’’ ’’
8.26.11 Set
8.27. External output 4
8.27.1 Weighing instrument ready to operate
’’ ’’
8.27.11 Set
8.28. External output 5
8.28.1 Weighing instrument ready to operate
’’ ’’
8.28.11 Set
