TABLE OF CONTENTS
ScanMasterII SMII 800, SMII 810, SMII 820, AND SMII 830 IRF/IEF
PARAGRAPH PAGE
© 2008, Satake USA Inc. INDEX - PAGE 2 OF 6
(ALL RIGHTS RESERVED)
SECTION 1 - GENERAL INFORMATION
1.0 SCOPE 1-1
1.1 SAFETY PRECAUTIONS 1-1
1.1.1 Voltages 1-1
1.1.2 Electrical Interlocks 1-1
1.1.3 Printed Circuit Card Removal 1-1
1.1.4 Disconnecting and Reconnecting Plugs and
Connectors
1-1
1.1.5 Compressed Air Cleaning 1-2
1.1.6 Removing and Installing Air Ejectors 1-2
1.2 BRIEF DESCRIPTION OF SORTING 1-2
1.3 INSTALLATION OF THE ScanMasterII 1-8
1.3.1 Location 1-8
1.3.2 Transporting the ScanMasterII 1-8
1.3.3 Installing the Feeders and Input Hopper 1-11
1.3.4 Connecting the Power 1-12
1.3.5 Connecting the Compressed Air 1-12
1.3.6 Dust Extraction 1-13
1.3.7 Other Considerations and Precautions
(WELDING, ETC...)
1-13
SECTION 2 - IDENTIFICATION AND FUNCTION OF PARTS
2.0 SCOPE 2-1
2.1 LOWER POWER ENCLOSURE 2-1
2.1.1 Cooling Fans 2-1
2.1.2 Power Transformer 2-1
2.1.3 Lower Power Supply 2-1
2.1.4 Lamp Ballasts 2-1
2.1.5 Lamp Current Sensor 2-3
2.1.6 Low Air Pressure Switch 2-3
2.1.7 System Interface PCB 2-3
2.2 CONTROL PANEL 2-3
2.2.1 Power On-Off Switch 2-3
2.2.2 Status Indicator 2-5
2.3 TOUCH SCREEN OPERATOR INTERFACE 2-5
2.3.1 Security Level 2-5
2.3.2 Language Options 2-7
2.4 MAIN SCREEN 2-7
2.4.1 Dark Trip Control 2-7
2.4.2 Light Trip Control 2-10
2.4.3 Feed Rate Control 2-10
2.4.4 Feeder On-Off Button 2-10
2.4.5 Hopper-Sensor Button 2-10
2.4.6 Ejectors On-Off Button 2-10
2.4.7 Wipe Button 2-12
2.4.8 Trip Rate Bar Graph 2-12
2.5 SETUP SCREENS 2-12
