Appendix D Parameters for Data Monitoring and Logging
PM135 Powermeter Series 157
Designation
Description
kvar IMP SD
kvar import sliding window demand
kVA SD
kVA sliding window demand
kW IMP ACD
kW import accumulated demand
kvar IMP ACD
kvar import accumulated demand
kVA ACD
kVA accumulated demand
kW IMP PRD
kW import predicted sliding window demand
kvar IMP PRD
kvar import predicted sliding window demand
kVA PRD
kVA predicted sliding window demand
PF IMP@kVA DMD
PF (import) at Maximum kVA sliding window demand
kW EXP BD
kW export block demand
kvar EXP BD
kvar export block demand
kW EXP SD
kW export sliding window demand
kvar EXP SD
kvar export sliding window demand
kW EXP ACD
kW export accumulated demand
kvar EXP ACD
kvar export accumulated demand
kW EXP PRD
kW export predicted sliding window demand
kvar EXP PRD
kvar export predicted sliding window demand
In DMD
In (neutral) current demand
SUMM ACC DMD
Billing Summary (Total) Accumulated Demands
E, EH
REG1 ACD
Register #1 accumulated demand
REG2 ACD
Register #2 accumulated demand
REG3 ACD
Register #3 accumulated demand
REG4 ACD
Register #4 accumulated demand
SUMM BLK DMD
Billing Summary (Total) Block Demands
E, EH
REG1 BD
Register #1 block demand
REG2 BD
Register #2 block demand
REG3 BD
Register #3 block demand
REG4 BD
Register #4 block demand
SUMM SW DMD
Billing Summary (Total) Sliding Demands
E, EH
REG1 SD
Register #1 sliding demand
REG2 SD
Register #2 sliding demand
REG3 SD
Register #3 sliding demand
REG4 SD
Register #4 sliding demand
ENERGY
Total Energy
E, EH
kWh IMPORT
kWh import
kWh EXPORT
kWh export
kvarh IMPORT
kvarh import
kvarh EXPORT
kvarh export
kVAh TOTAL
kVAh total
SUMMARY REGS
Billing Summary (Total) Energy Registers
E, EH
SUM REG1
Summary energy register #1
SUM REG2
Summary energy register #2
SUM REG3
Summary energy register #3
SUM REG4
Summary energy register #4
PHASE ENERGY
Phase Energy
E, EH
kWh IMP L1
kWh import L1
kWh IMP L2
kWh import L2
kWh IMP L3
kWh import L3
kvarh IMP L1
kvarh import L1
kvarh IMP L2
kvarh import L2
kvarh IMP L3
kvarh import L3
